Power source switch three-position+N (N pole non-switchable) PRZK-3125N\W01

local index:
ALK960SPAM
Catalog No:
PRZK-3125N\W01
EAN code:
5907723010086
Manufacturer: SPAMEL
Rated insulation voltage [V]: 690
Continuous current [A]: 125
Level of security: IP20
Price:
244,17 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to a week (working days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

PRZK power source switches are built on the basis of RSI disconnectors, therefore they have all the features of these disconnectors. PRZK switches are a structural connection, with one common cover, of two RSI type switch disconnectors. This solution ensures excellent rigidity of the system, and thus, operational reliability and safety of use. PRZK switches equipped with a specially designed coupler are a comprehensive solution to the need to switch types of power supply, e.g. Network - Aggregate type.

Technical data

  • Rated insulation voltage [V]
    690
  • Level of security
    IP20
  • Continuous current [A]
    125

Other technical data

  • Model
    Reverser
  • With zero (off) position
    Yes
  • Rated permanent current Iu
    125 A
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Suitable for front mounting
    No
  • Suitable for intermediate mounting
    Yes
  • Housing material
    Plastic
  • Type of electrical connection of main circuit
    Screw connection
  • Number of poles
    3
  • With retraction in 0-position
    No
  • Degree of protection (IP), front side
    IP65
  • Number of auxiliary contacts as normally open contact
    0
  • Suitable for floor mounting
    Yes
  • Suitable for distribution board installation
    No
  • Complete device in housing
    No
  • Type of control element
    Turn button
