Miniature relay RM84-2312-35-5230 651258

local index:
APE313RELP
Catalog No:
651258
Manufacturer: RELPOL
Depth [mm]: 29
Pin configuration: 2P
AC coil voltage [V]: 230
Price:
11,72 €
gross / pcs.
(including VAT 23%)
837,14 € gross/kg.
Delivery in 3h
Accessible 178 pcs.
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Electromagnetic relay RM84-2312-35-5230, miniature, for PCB and plug-in socket.

  • 5 mm pitch.
  • Output: 2P - two changeover contacts - terminals: 11(7)-12(6)-14(8); 21(4)-22(3)-24(5); AC1 - 8A / 250V; DC1 - 8 A / 24 V.
  • Input / coil - terminals: A1(1) - A2(2)
  • Contact material: AgNi/Au hard gold plating.
  • Socket mounting options: EC50, GD50, PW80 - for printing; GZP80 (push-in), GZT80, GZM80, GZS80, GZF80 - mounting on a 35 mm rail or screwed to the panel with one M3 screw; GZMB80 - screwless socket, mounting on a 35 mm rail.
  • Rated current AC1: 8A / 230V AC
  • Rated current AC3: 0.37kW
  • Rated current DC1: 8A / 24V DC
  • Way of connection: to plug-in sockets and PCB assembly

Technical data

  • Depth [mm]
    29
  • AC coil voltage [V]
    230
  • Width [mm]
    12.7
  • Height [mm]
    15.7
  • Pin configuration
    2P
  • Rated current [A]
    8
  • Weight [g]
    14
