Electromagnetic relay RM85-2011-35-5230 miniature for printed circuit and plug socket 604658
local index:
APE158RELP
Catalog No:
604658
Price:
150,20 €
gross / pkg.
(including VAT 23%)
7,51 € gross/pcs.
Delivery in 3h
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Electromagnetic relay, miniature, for PCB and plug-in socket.
5 mm pitch.
Height 15.7 mm.
< br/>Output: 1P - one changeover contact - terminals: 11(7)/21(4)-12(6)/22(3)-14(8)/24(5); AC1 - 16A / 250V; DC1 - 16 A / 24 V.
Input / coil - terminals: A1(1) - A2(2), supply voltage Un - 230 V AC. Dimensions: 29 x 12.7 x 15.7 mm.
Contact material: AgNi. IP 67.
Socket mounting options: EC50, GD50 - for printing; GZT80, GZM80, GZS80 - mounting on a 35 mm rail or screwed to the board with one M3 screw.
Note: there are galvanic connections in the relay: 11 with 21, 12 with 22 and 14 of 24.
Technical data
-
Level of securityIP67
-
Height [mm]15.7
-
Pieces in the package20
Other technical data
-
Type of electric connectionPCB connection
-
Rated control supply voltage AC 60 Hz230 ... 230 V
-
Voltage type for actuatingAC
-
Drive, switching attitudeMono stable
-
Number of contacts as normally open contact0
-
Type of switch contactSingle contact
-
Degree of protection (IP)IP67
-
Height15.7 mm
-
Rated control supply voltage AC 50 Hz230 ... 230 V
-
Rated control supply voltage DC0 ... 0 V
-
Drive, polarizationPolarity free
-
Number of contacts as normally closed contact0
-
Number of contacts as change-over contact1
-
Complete with socketNo
-
Width12.7 mm
-
Depth29 mm
Manufacturer details
-
ManufacturerRELPOL S.A.
-
Address68-200 Żary 11 Listopada 37
-
Phone number
-
E-mail
-
Tax identification number9280007076
-
GLN5909000713000
