Wall-mounted junction box 118x118x68 IP67 white 35137206

local index:
MVN004SIME
Catalog No:
35137206
EAN code:
5907813218415
Manufacturer: SIMET
Halogen free: Yes
Depth [mm]: 68
Color: White
Price:
157,13 €
gross / pkg.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Print

Product description

Wall box

  • With a rubber gasket in the lid
  • Sealable. Fastening to the ground also with electrotechnical clamps
  • The cover is screwed with acid-resistant screws
  • Convenient knockouts for inserting pipes and wires (7 knockouts with a diameter of 23 and 28mm - for a screwed gland PG16 or PG21)
  • Accessories matching the box:
    • PG16 and PG21 screw glands

Technical data

  • Halogen free
    Yes
  • Color
    White
  • Material
    Polyamide
  • UV resistance
    Yes
  • Type
    Wall-mounted
  • Width [mm]
    118
  • Height [mm]
    118
  • Fire resistance
    Non-flammable
  • Fire resistance [°C]
    960
  • With terminal strip
    NO
  • Stuffing box type
    PG21 PG16
  • PKWIU
    27.33.13.0
  • Depth [mm]
    68
  • Shape
    Square
  • Installation
    Surface-mounted
  • Cover
    Yes
  • Level of security
    IP67
  • Type
    branching
  • Self-extinguishing
    Yes
  • Flammability class
    V0
  • For modular equipment
    Not applicable
  • Number of slots
    7
  • Exact material
    PA6

Other technical data

  • Equipped with
    Other
  • Mounting method
    Wall-/ceiling mounting
  • Inlet from the rear
    No
  • Width
    120 mm
  • Tackable
    Yes
  • Type of housing feed-through
    Preembossing
  • Halogen free
    Yes
  • Colour
    White
  • Pokrywa
    Nieprzezroczyste
  • Sealable
    No
  • Weatherproof
    No
  • Shape
    Square
  • For tube diameter
    Other
  • Length
    120 mm
  • Depth
    64 mm
  • Number of inlets
    7
  • Material
    Plastic
  • Surface protection
    Other
  • Degree of protection (IP)
    IP67
  • Cover attachment
    Screwed
  • With screening
    No
  • Explosion-tested version
