W.1 Schuko socket 2P+E for key various locks with description field complete IP55 gray 47393505
local index:
MFB043BERK
Catalog No:
47393505
EAN code:
4011334395010
Price:
66,09 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Hermetic wall-mounted electric socket from the W.1 series, from the manufacturer Berker. The product part number is 47393505.
FEATURES
- 2P+Z.
- With SCHUKO grounding.
- With extended contact protection.
- Key-operated.
- With lockable cover, manually locked.
- With plug-in terminals.
- With 2-wire entry and entry cable or pipe.
- With a full-surface seal on the rear side of the housing, enabling the cable to be inserted from the rear side and adjustment to the plaster.
- The height of the description field is adapted to the P-touch strip 12 mm.< /li>
- Hinged cover, made of stainless steel, quick-release pins, ZAMAK lock.
- With self-locking screws.
SERIES DESCRIPTION
Berker W.1 is a series of waterproof electrical installation equipment, which is distinguished by its innovative design. Hermetic surface-mounted electrical socket characterizes the features of this series.
Technical data
-
Number of sockets1
-
ShapeSquare
-
InstallationSurface-mounted
-
Descriptive fieldYes
-
TypeElectrical hermetic
-
Level of securityIP55
-
TypeSurface-mounted
-
Height [mm]76
-
Surface finishmatte
-
Wire cross-section [mm²]1 - 2.5
-
Terminal typeThreadless
-
Shutters of current pathsYes
-
For the frame systemNO
-
Additional informationLocked
-
SealYes
-
ColorGray
-
MaterialPlastic
-
Rated voltage [V]230
-
Rated current [A]16
-
FamilyW.1
-
Width [mm]76
-
Groundschuko
-
Degree of mechanical protectionIK05
-
Accurate colordark grey
-
BacklightNO
-
StandardEuropean
-
On the DATA keyNO
-
Lid colorSocket color
-
Exact materialThermoplastic
-
PKWIU27.33.13.0
Other technical data
-
ModelProtective contact CEE 7/3 / CEE 7/4 (type F)
-
Okrągły styk ochronnyNo
-
Number of active contacts (flat)0
-
With built-in USB power supplyNo
-
Number of modules (module system)0
-
Number of phases1
-
With hinged lidYes
-
Label space/information surfaceYes
-
RAL-number (similar)7011
-
LockableYes
-
Insulated mountingYes
-
With orientation lightingNo
-
Fault current protectionNo
-
Special power supplyNo special power supply
-
Type of fasteningMounting with screw
-
Material qualityThermoplastic
-
Surface protectionUntreated
-
Anti-bacterial treatmentNo
-
With loop through functionNo
-
Nominal current16 A
-
Frequency50 ... 60 Hz
-
Suitable for degree of protection (IP)IP55
-
Device width76 mm
-
Device depth65 mm
-
Protective contactYes
-
Number of active contacts (round)2
-
With signal lampNo
-
Number of units1
-
Number of socket outlets switchable0
-
Connection typePush-in clamp
-
With enhanced contact protectionYes
-
ColourGrey
-
TransparentNo
-
Eject-mechanismNo
-
With function lightingNo
-
Over voltage protectionNo
-
With miniature fuseNo
-
Mounting methodSurface mounted
-
MaterialPlastic
-
Halogen freeYes
-
Surface finishingMatt
-
With on/off switchNo
-
Rotated central insertNo
-
Nominal voltage250 V
-
Rated fault current0 mA
-
Impact strengthIK05
-
Device height76 mm
-
Min. depth of built-in installation box0 mm
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 36 pcs. | 1152 pcs. |
| Weight (kg) | 0,146 | 0,160 | 6,200 | 221,400 |
| Width (m) | 0,076 | 0,085 | 0,300 | 0,800 |
| Length (m) | 0,065 | 0,070 | 0,225 | 1,050 |
| Depth (m) | 0,076 | 0,080 | 0,400 | 1,200 |
