W.1 Schuko socket 2P+E complete IP55 white 47403512

Index local:
MFB001BERK
Numéro de catalogue:
47403512
Code EAN:
4011334404224
Producteur: BERKER
Number of sockets: 1
Color: White
Shape: Square
Prix:
106,27 zł
gross / pcs.
(y compris la TVA 23%)
jusqu'à 10 semaines
Sur commande
Quantité pcs.
(plusieurs:
1
)
Ajouter à la demande de devis
Ajouter au presse-papiers
Imprimer

Description du produit

Hermetic wall-mounted electric socket from the W.1 series, from the manufacturer Berker. The product part number is 47403512.



FEATURES

  • 2P+Z.
  • With SCHUKO ground connection.
  • Colour white.
  • With lockable lid, manually locked.
  • Rated current of the socket 16 A.
  • Rated voltage 230 V.
  • Degree of protection IP55.
  • Mounting surface.
  • With Wago 2-pole wiring connector.
  • < li>With 2 clips for Wago 2-pole connection terminal on the underside of the housing.
  • With plug-in terminals.
  • With 2-wire entry and cable or pipe entry.
  • With a full-area seal on the back of the housing, enabling cable entry from the back and fitting to the plaster.
  • Hinged cover, made of stainless steel, quick-release pins, ZAMAK lock.
  • < li>With self-clamps.



SERIES DESCRIPTION

Berker W.1 is a series of waterproof electrical installation accessories , which is distinguished by its innovative appearance. Hermetic surface-mounted electrical socket characterizes the features of this series.

Données techniques

  • Number of sockets
    1
  • Shape
    Square
  • Installation
    Surface-mounted
  • Rated current [A]
    16
  • Family
    W.1
  • Width [mm]
    76
  • Ground
    schuko
  • Degree of mechanical protection
    IK05
  • Backlight
    NO
  • Standard
    European
  • On the DATA key
    NO
  • Lid color
    Socket color
  • Seal
    Yes
  • Color
    White
  • Material
    Plastic
  • Rated voltage [V]
    230
  • Type
    Electrical hermetic
  • Level of security
    IP55
  • Type
    Surface-mounted
  • Height [mm]
    76
  • Surface finish
    matte
  • Terminal type
    Threadless
  • Shutters of current paths
    NO
  • For the frame system
    NO
  • Exact material
    Thermoplastic
  • PKWIU
    27.33.13.0

Autres données techniques

  • Protective contact
    Earthing clips
  • Number of active contacts (flat)
    0
  • Number of ports USB-A
    0
  • Number of modules (module system)
    0
  • Number of phases
    1
  • With hinged lid
    Yes
  • Label space/information surface
    No
  • Metallic colour
    No
  • Lockable
    No
  • Insulated mounting
    Yes
  • With orientation lighting
    No
  • Fault current protection
    No
  • Halogen free
    Yes
  • Anti-bacterial treatment
    No
  • With on/off switch
    No
  • Nominal current
    16 A
  • Frequency
    50 ... 60 Hz
  • Device width
    76 mm
  • Device depth
    63 mm
  • Compatible with Apple HomeKit
    No
  • Compatible with Google Assistant
    No
  • For heavy conditions according to VDE
    No
  • Number of active contacts (round)
    2
  • With signal lamp
    No
  • Number of ports USB-C
    0
  • Number of socket outlets switchable
    0
  • Imprint/indication
    None
  • With enhanced contact protection
    No
  • RAL-number (similar)
    9010
  • Transparent
    No
  • Eject-mechanism
    No
  • With function lighting
    No
  • Over voltage protection
    No
  • With miniature fuse
    No
  • Surface finishing
    Matt
  • With loop through function
    No
  • Rotated central insert
    No
  • Nominal voltage
    250 V
  • Rated fault current
    0 mA
  • Device height
    76 mm
  • Min. depth of built-in installation box
    0 mm
  • Compatible with Amazon Alexa
    No
  • IFTTT support available
    No

Détails du fabricant

Emballage en vrac

Une sorte de paquet Karton Pakiet Paleta
Quantité 1 pcs. 36 pcs. 1152 pcs.
poids (kg) 0,140 5,480 198,360
Largeur (m) 0,080 0,300 0,800
Longueur (m) 0,070 0,220 1,050
Profondeur (m) 0,080 0,400 1,200
