W.1 Schuko 2P+E key socket with description field various complete locks IP55 white 47693502

Внутрішній артикул:
MFB006BERK
№ каталоговий:
47693502
Код EAN:
4011334395089
Виробник: BERKER
Number of sockets: 1
Color: White
Shape: Square
Ціна:
311,37 zł
gross / шт.
(з ПДВ 23%)
до 10 тижнів
На замовлення
Кількість шт.
(багаторазовий:
1
)
Додати до запиту на пропозицію
Додати в буфер обміну
Роздрукувати

Опис товару

Hermetic wall-mounted electric socket from the W.1 series, from the manufacturer Berker. The product part number is 47693502.



FEATURES

  • 2P+Z.
  • With SCHUKO grounding.
  • With extended contact protection.
  • Key-operated.
  • Color white.
  • With lockable cover, manually locked.
  • Rated current of the socket  ;16A.
  • Rated voltage 230V.
  • Rating IP55.
  • surface mounting.
  • With plug-in terminals.
  • With 2-wire entry and cable or pipe entry.
  • With a full-surface seal on the rear side of the housing, enabling cable entry from the rear side and fitting to the plaster.
  • The height of the labeling field is adapted to the 12 mm P-touch strip.
  • The cover on the hinged, stainless steel, ZAMAK quick-release pins.
  • With self-clamps.



SERIES DESCRIPTION

Berker W.1 is a series of waterproof electrical installation accessories, which is distinguished by its innovative design. Hermetic surface-mounted electrical socket characterizes the features of this series.

Технічні дані

  • Number of sockets
    1
  • Shape
    Square
  • Installation
    Surface-mounted
  • Descriptive field
    Yes
  • Type
    Electrical hermetic
  • Level of security
    IP55
  • Type
    Surface-mounted
  • Height [mm]
    76
  • Surface finish
    matte
  • Terminal type
    Threadless
  • Shutters of current paths
    Yes
  • For the frame system
    NO
  • Additional information
    Locked
  • Seal
    Yes
  • Color
    White
  • Material
    Plastic
  • Rated voltage [V]
    230
  • Rated current [A]
    16
  • Family
    W.1
  • Width [mm]
    76
  • Ground
    schuko
  • Degree of mechanical protection
    IK05
  • Backlight
    NO
  • Standard
    European
  • On the DATA key
    NO
  • Lid color
    Socket color
  • Exact material
    Thermoplastic
  • PKWIU
    27.33.13.0

Інші технічні дані

  • Number of active contacts (round)
    2
  • With signal lamp
    No
  • Number of socket outlets switchable
    0
  • Imprint/indication
    None
  • With hinged lid
    Yes
  • Label space/information surface
    Yes
  • Metallic colour
    No
  • Lockable
    Yes
  • Insulated mounting
    Yes
  • With orientation lighting
    No
  • Fault current protection
    No
  • Type of fastening
    Mounting with screw
  • Surface finishing
    Matt
  • With loop through function
    No
  • Rotated central insert
    No
  • Nominal voltage
    250 V
  • Rated fault current
    0 mA
  • Device height
    76 mm
  • Min. depth of built-in installation box
    0 mm
  • Compatible with Amazon Alexa
    No
  • IFTTT support available
    No
  • Number of active contacts (flat)
    0
  • Number of modules (module system)
    0
  • Number of phases
    1
  • Connection type
    Push-in clamp
  • With enhanced contact protection
    Yes
  • RAL-number (similar)
    9010
  • Transparent
    No
  • Eject-mechanism
    No
  • With function lighting
    No
  • Over voltage protection
    No
  • With miniature fuse
    No
  • Halogen free
    Yes
  • Anti-bacterial treatment
    No
  • With on/off switch
    No
  • Nominal current
    16 A
  • Frequency
    50 ... 60 Hz
  • Device width
    76 mm
  • Device depth
    65 mm
  • Compatible with Apple HomeKit
    No
  • Compatible with Google Assistant
    No
  • For heavy conditions according to VDE
    No

Інформація про виробника

  • Виробник
    Hager Electro S.A.S.
  • Адреса
    FR 67215 Obernai 123 boulevard d’Europe Francja
  • Електронна пошта

Об'ємна упаковка

Свого роду пакет Karton Pakiet Paleta
Кількість 1 шт. 36 шт. 1152 шт.
Вага (кг) 0,170 5,732 203,417
Ширина (м) 0,080 0,300 0,800
Довжина (м) 0,070 0,220 1,050
Глибина (м) 0,080 0,400 1,200
