el12 Electrical equipment Sockets Surface-mounted sockets
el12 Electrical equipment Sockets Hermetic electrical sockets
el12 sale Get in the game - HAGER

W.1 Earthed socket 2P+E complete 2-way horizontal IP55 white 6768833512

Indice locale:
MFB028BERK
Numero di catalogo:
6768833512
Codice EAN:
4011334390909
W.1 Earthed socket 2P+E complete 2-way horizontal IP55 white
W.1 Earthed socket 2P+E complete 2-way horizontal IP55 white
W.1 Earthed socket 2P+E complete 2-way horizontal IP55 white
W.1 Earthed socket 2P+E complete 2-way horizontal IP55 white

Clicca sulla foto per ingrandire

Produttore: BERKER
Number of sockets: 3
Color: White
Shape: Rectangular
Vedi la descrizione completa
Prezzo:
251,14 zł
gross / pezzi
(inclusa IVA 23%)
fino a 10 settimane
Su ordinazione
Quantità pezzi
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa
Descrizione del prodotto Dati tecnici Dettagli del produttore Imballaggio sfuso File da scaricare

Descrizione del prodotto

Hermetic wall-mounted electric socket from the W.1 series, from the manufacturer Berker. The product catalog number is 6768833512.



FEATURES

  • 3 x 2P+Z.
  • Triple.
  • 2-pole grounding; ground pin.
  • Horizontal.
  • Color snow white.
  • Rated current 16 A.
  • Rated voltage 230V.
  • Ingress protection IP55.
  • surface mounting.
  • For screw connection.
  • With plug-in terminals.
  • With one entry for two cables and one cable or pipe entry.
  • With a full-surface seal on the rear side of the housing for cable entry from the rear side and plaster fit.
  • Stainless steel latch springs, latch pins ;w of ZnAl alloy.
  • With self-clamps.



SERIES DESCRIPTION

Berker W .1 is a series of waterproof electrical installation equipment, which is distinguished by its innovative design. Hermetic surface-mounted electrical socket characterizes the features of this series.

Dati tecnici

  • Number of sockets
    3
  • Shape
    Rectangular
  • Installation
    Surface-mounted
  • Rated current [A]
    16
  • Family
    W.1
  • Type
    Surface-mounted
  • Height [mm]
    76
  • Accurate color
    Snow white
  • Mounting direction
    Horizontal
  • Shutters of current paths
    NO
  • For the frame system
    NO
  • Exact material
    Thermoplastic
  • PKWIU
    27.33.13.0
  • Color
    White
  • Material
    Plastic
  • Rated voltage [V]
    230
  • Type
    Electrical hermetic
  • Level of security
    IP55
  • Ground
    Hurt
  • Surface finish
    matte
  • Backlight
    NO
  • Standard
    European
  • On the DATA key
    NO
  • Lid color
    Socket color
  • Seal
    Yes

Altri dati tecnici

  • Model
    Earthing pin
  • Number of active contacts (flat)
    0
  • Number of modules (module system)
    0
  • Number of phases
    1
  • With hinged lid
    Yes
  • Label space/information surface
    No
  • RAL-number (similar)
    9010
  • Lockable
    No
  • Insulated mounting
    Yes
  • With orientation lighting
    No
  • Fault current protection
    No
  • Mounting method
    Surface mounted
  • Material
    Plastic
  • Halogen free
    Yes
  • Surface finishing
    Matt
  • With loop through function
    No
  • Rotated central insert
    No
  • Nominal voltage
    250 V
  • Rated fault current
    0 mA
  • Impact strength
    IK05
  • Device height
    76 mm
  • Compatible with Amazon Alexa
    No
  • IFTTT support available
    No
  • Number of active contacts (round)
    2
  • With signal lamp
    No
  • Number of socket outlets switchable
    0
  • Imprint/indication
    None
  • With enhanced contact protection
    No
  • Colour
    White
  • Transparent
    No
  • Eject-mechanism
    No
  • With function lighting
    No
  • Over voltage protection
    No
  • With miniature fuse
    No
  • Type of fastening
    Mounting with screw
  • Material quality
    Thermoplastic
  • Surface protection
    Untreated
  • Anti-bacterial treatment
    No
  • With on/off switch
    No
  • Nominal current
    16 A
  • Frequency
    50 ... 60 Hz
  • Suitable for degree of protection (IP)
    IP55
  • Device width
    218 mm
  • Compatible with Apple HomeKit
    No
  • Compatible with Google Assistant
    No
  • For heavy conditions according to VDE
    No

Dettagli del produttore

Imballaggio sfuso

Una specie di pacchetto Karton Pakiet Paleta
Quantità 1 pezzi 15 pezzi 480 pezzi
Peso (kg) 0,410 6,592 230,944
Larghezza (m) 0,080 0,300 0,800
Lunghezza (m) 0,070 0,220 1,050
Profondità (m) 0,220 0,400 1,200
