W.1 Earthed 2-way socket with cover IP55 grey WNC132B
local index:
MFB030BERK
Catalog No:
WNC132B
EAN code:
3250617171359
Price:
34,35 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Hermetic wall-mounted electric socket from the W.1 series, from the manufacturer Berker. The product part number is WNC132B.
FEATURES
- Double .
- With earthing; ground pin.
- Pole arrangement 2P+T.
- Color white.
- Rated current 16 A.
- Rated voltage 230 V.
- Rating IP55.
- Surface mounting.
- Clamp connection.
- Screw mounting.
- Through the rigid duct ( wire) in clamp: min. 2x1mm² - max. 2x2.5 mm².
- Connection type: Quick Connect.
- Phase branch: L1.
Technical data
-
Depth [mm]22.8
-
ColorWhite
-
MaterialPlastic
-
Rated voltage [V]230
-
TypeElectrical hermetic
-
Level of securityIP55
-
TypeSurface-mounted
-
GroundHurt
-
BacklightNO
-
Shutters of current pathsNO
-
For the frame systemNO
-
Exact materialPP
-
Number of sockets2
-
ShapeRectangular
-
InstallationSurface-mounted
-
Rated current [A]16
-
FamilyW.1
-
Width [mm]76
-
Connection typeQuick Connect
-
Degree of mechanical protectionIK07
-
StandardEuropean
-
On the DATA keyNO
-
Lid colorSocket color
-
PKWIU27.12.40.0
Other technical data
-
Okrągły styk ochronnyYes
-
Number of active contacts (flat)0
-
With built-in USB power supplyNo
-
Number of socket outlets switchable0
-
Connection typePush-in clamp
-
With enhanced contact protectionNo
-
ColourWhite
-
TransparentNo
-
Eject-mechanismNo
-
With function lightingNo
-
Over voltage protectionNo
-
Special power supplyNo special power supply
-
Type of fasteningMounting with screw
-
Material qualityOther
-
Surface finishingMatt
-
With on/off switchNo
-
Rotated central insertNo
-
Nominal voltage250 V
-
Suitable for degree of protection (IP)IP55
-
Device width75 mm
-
Device depth22.8 mm
-
Number of active contacts (round)1
-
With signal lampNo
-
Number of modules (module system)4
-
Imprint/indicationOther
-
With hinged lidYes
-
Label space/information surfaceNo
-
RAL-number (similar)9010
-
LockableNo
-
Insulated mountingYes
-
With orientation lightingNo
-
With miniature fuseNo
-
Mounting methodOther
-
MaterialPlastic
-
Surface protectionLacquered
-
Anti-bacterial treatmentNo
-
With loop through functionYes
-
Nominal current16 A
-
Frequency50 ... 60 Hz
-
Impact strengthIK07
-
Device height75 mm
-
Min. depth of built-in installation box40 mm
Manufacturer details
-
ManufacturerHAGER POLO Sp. z o. o.
-
Address43-100 Tychy Fabryczna 10
-
E-mail
-
Tax identification number6460015532
-
GLN5900009931532
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 16 pcs. | 384 pcs. |
| Weight (kg) | 0,240 | 0,268 | 4,777 | 134,648 |
| Width (m) | 0,147 | 0,078 | 0,306 | 0,800 |
| Length (m) | 0,065 | 0,065 | 0,210 | 1,050 |
| Depth (m) | 0,076 | 0,149 | 0,356 | 1,200 |
