TEHALIT.WA Installation box for installation in C-profiles universal light gray GLT5010

local index:
MVN012TEHA
Catalog No:
GLT5010
EAN code:
4012740871716
Manufacturer: TEHALIT
Halogen free: Yes
Depth [mm]: 50
Color: Gray
Price:
6,49 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Installation box

  • Mounting in C-profiles.
  • For ICT/antenna sockets.
  • Made of polyamide.
  • Screw-on.
  • Anti-pull protection possible.
  • Compatible socket type: 60mm standard.
  • With connection space: no.

Technical data

  • Halogen free
    Yes
  • Color
    Gray
  • Material
    Polyamide
  • Cover
    NO
  • Family
    TEHALIT.WA
  • Type
    For attachments
  • Accurate color
    light gray
  • Number of segments
    1
  • With terminal strip
    NO
  • Depth [mm]
    50
  • Shape
    Square
  • Installation
    Surface-mounted
  • Type
    To the channels
  • Width [mm]
    64
  • Height [mm]
    71
  • Fire resistance
    Not applicable
  • For modular equipment
    Not applicable
  • PKWIU
    22.23.19.0

Other technical data

  • Number of units
    1
  • Model
    Open
  • Mounting track
    60 mm
  • Strain relief possibility
    Yes
  • Material
    Plastic
  • Mounting method box
    Rear panel
  • Type of device
    With bearer ring/bearer bracket
  • Mounting method installation unit
    Screwing
  • With connection space
    No

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 1 pcs. 75 pcs. 1800 pcs.
Weight (kg) 0,036 0,042 3,550 110,200
Width (m) 0,067 0,075 0,384 0,800
Length (m) 0,060 0,060 0,225 1,050
Depth (m) 0,071 0,060 0,400 1,200
