SIMET

Self-locking wall box 98x98x60mm IP54 35220002

local index:
MVN006SIME
Catalog No:
35220002
EAN code:
5907813212109
Price:
53,42 €
gross / pkg.
including VAT 23%
Availability:
up to 4 weeks (business days)
Delivery:
From 3,47 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pkg.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details

Product description

Wall box

  • Sealable. Fastening to the ground also with electrotechnical clamps
  • With a self-locking cover
  • 4 knockouts on the cover for screwing it with W16 screws
  • Convenient knockouts for inserting pipes and wires (7 knockouts with internal diameters from 7 to 25mm)
  • Accessories matching the box:
    • Branch connectors: ZPT 4x2.5, ZPT 5x2.5, ZPT 4x4.0, ZPT 5x4.0, ZPT 5x10

Technical data

  • Depth [mm]
    60
  • Shape
    Square
  • Installation
    Surface-mounted
  • Type
    Wall-mounted
  • Width [mm]
    98
  • Type
    branching
  • Self-extinguishing
    Yes
  • Fire resistance [°C]
    650
  • With terminal strip
    NO
  • Color
    Gray
  • Material
    PE
  • Cover
    Yes
  • Level of security
    IP54
  • Pieces in the package
    28
  • Height [mm]
    98
  • Fire resistance
    Not applicable
  • For modular equipment
    Not applicable
  • Number of slots
    7

Other technical data

  • Max. conductor cross section
    10 mm²
  • Shape
    Square
  • For tube diameter
    Other
  • Length
    93 mm
  • Depth
    55 mm
  • Number of inlets
    7
  • Material
    Plastic
  • Surface protection
    Other
  • Degree of protection (IP)
    IP54
  • Cover attachment
    Snapped on
  • With screening
    no
  • Explosion-tested version
  • Equipped with
    Other
  • Mounting method
    Wall-/ceiling mounting
  • Inlet from the rear
    no
  • Width
    93 mm
  • Tackable
    yes
  • Type of housing feed-through
    Trimmable step membrane
  • Halogen free
    no
  • Colour
    Grey
  • Pokrywa
    Nieprzezroczyste
  • Sealable
    no
  • Weatherproof
    no
