Self-locking wall box 88x88x58mm IP54 gray 35210002

Lokaler Index:
MVN005SIME
Katalognummer:
35210002
EAN-Code:
5907813212123
Hersteller: SIMET
Depth [mm]: 58
Color: Gray
Shape: Square
Preis:
2,29 €
gross / stk.
(inklusive MwSt 23%)
Lieferung in 3h
bis zu 4 Wochen (Arbeitstage)
Abholung in 1 Stunde
Menge stk.
(mehrere:
1
)
Zur Zwischenablage hinzufügen
Drucken

Produktbeschreibung

Wall box

  • Sealable. Fastening to the ground also with electrotechnical clamps
  • With a self-locking cover
  • 4 knockouts on the cover for screwing it with W16 screws
  • Convenient knockouts for inserting pipes and wires (7 knockouts with internal diameters from 7 to 21mm)
  • Accessories matching the box:
    • Branch connectors: ZPT 4x2.5, ZPT 5x2.5, ZPT 4x2.5, ZPT 5x4.0

Technische Daten

  • Depth [mm]
    58
  • Shape
    Square
  • Installation
    Surface-mounted
  • Type
    Wall-mounted
  • Width [mm]
    88
  • Height [mm]
    88
  • Fire resistance
    Not applicable
  • For modular equipment
    Not applicable
  • Number of slots
    7
  • Color
    Gray
  • Material
    PE
  • Cover
    Yes
  • Level of security
    IP54
  • Type
    branching
  • Self-extinguishing
    Yes
  • Fire resistance [°C]
    650
  • With terminal strip
    NO
  • PKWIU
    27.33.13.0

Weitere technische Daten

  • Max. conductor cross section
    2,5 mm²
  • Shape
    Square
  • For tube diameter
    Other
  • Length
    83 mm
  • Depth
    52 mm
  • Number of inlets
    7
  • Material
    Plastic
  • Surface protection
    Other
  • Degree of protection (IP)
    IP54
  • Cover attachment
    Screwed
  • With screening
    No
  • Explosion-tested version
  • Equipped with
    Other
  • Mounting method
    Wall-/ceiling mounting
  • Inlet from the rear
    No
  • Width
    83 mm
  • Tackable
    Yes
  • Type of housing feed-through
    Trimmable step membrane
  • Halogen free
    No
  • Colour
    Grey
  • Pokrywa
    Nieprzezroczyste
  • Sealable
    No
  • Weatherproof
    No

Hersteller-Details

  • Hersteller
    SIMET S.A.
  • Adresse
    58-506 Jelenia Góra al. Jana Pawła II 33 Polska

Großpackungen

Eine Art Paket Pakiet
Menge 1 stk.
Breite (m) 0,088
Länge (m) 0,088
