Q.1 Single surface-mounted box, black mat 10296086

Name: Q.1 Single surface-mounted box, black mat
Brand: BERKER
SKU: MVN010BERK
Price: 57.48 PLN
Availability: BackOrder

Index local:

MVN010BERK

Numéro de catalogue:

10296086

Code EAN:

4011334386124

Q.1 Single surface-mounted box, black mat

Cliquer sur la photo pour l'agrandir

Producteur: BERKER

Halogen free: Yes

Depth [mm]: 35

Color: Black

Voir la description complète

Prix:

57,48 zł

gross / pcs.

(y compris la TVA 23%)

jusqu'à 10 semaines

Sur commande

Quantité pcs.

(plusieurs:

)

Ajouter à la demande de devis

Ajouter au presse-papiers

Imprimer

Renseignez-vous sur le produit

Description du produit Données techniques Détails du fabricant Emballage en vrac Fichiers à télécharger

Description du produit

One-gang surface mounted box, Berker Q.1 series. After removing the frame, the description field remains on the mechanism.

Characteristics of the series:

A series whose surface resembles velvet. This delicacy, combined with a classic shape, makes this fitting perfectly match both modern and traditional interiors.

made of duroplast - a high-quality material resistant to scratches and mechanical damage,
antistatic,
resistance to chemicals contained in cleaning products,
resistance to high temperatures and UV radiation.

Données techniques

Halogen free

Yes
Color

Black
Material

Plastic
Cover

NO
Family

Q.1
Width [mm]

85
Height [mm]

85
Accurate color

Black mat
Mounting direction

Universal
For modular equipment

Not applicable
Exact material

Duroplastic

Depth [mm]

35
Shape

Square
Installation

Surface-mounted
Type

Wall-mounted
Level of security

IP20
Type

For attachments
Surface finish

matte
Fire resistance

Not applicable
Number of segments

1
With terminal strip

NO
PKWIU

27.12.40.0

Autres données techniques

Assembly arrangement

Surface mounted frame
Suitable for modular domestic switching devices

No
Mounting direction

Horizontal
Material

Plastic
Halogen free

Yes
Surface finishing

Matt
RAL-number (similar)

7021
With cover frame

No
With cable entry

Yes
With installation tube entry

Yes
Number of earthing terminals

0
Width

85.15 mm
Depth

34.75 mm

Suitable for mounting over existing flush-mounted box

Yes
Number of modules (module system)

1
Desktop device

No
Material quality

Duroplast
Surface protection

Lacquered
Colour

Anthracite
Transparent

No
With duct entry

Yes
With screw gland entry

No
Number of inlets

2
Degree of protection (IP)

IP20
Height

84.7 mm
Compliant with BS 4662

No

Détails du fabricant

Producteur

Berker GmbH & Co. KG.
Adresse

DE 66440 Blieskastel Zum Gunterstal Niemcy
E-mail

wsparcie.klienta@hager.com

Emballage en vrac

Une sorte de paquet	Karton	Pakiet	Paleta
Quantité	10 pcs.	40 pcs.	1280 pcs.
poids (kg)	1,040	4,515	169,480
Largeur (m)	0,190	0,300	0,800
Longueur (m)	0,100	0,220	1,050
Profondeur (m)	0,230	0,400	1,200
