Airtight box for empty walls with diaphragms fi60mm deep orange 83192088

local index:
MVP064SIME
Catalog No:
83192088
EAN code:
4034338913073
Manufacturer: SIMET
Depth [mm]: 61
Color: Orange
Shape: Round
Price:
51,88 €
gross / pkg.
(including VAT 23%)
2,08 € gross/pcs.
Delivery in 3h
2 weeks
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

A box for empty walls windproof with membranes.

Features:

  • VDE certificate.
  • 4 cable glands : (2x) M 25, (2x) 3x1.5mm2, (2x) 3x2.5mm2-5x1.5mm2.
  • Additional 2 cable glands for 7x1.5mm2 or 5x2.5mm2.
  • < li>Includes 2 screws for mounting the accessories.

Accessories matching the box:

  • PL60 protective cover
  • E105 connector

Technical data

  • Depth [mm]
    61
  • Shape
    Round
  • Installation
    Flush-mounted
  • Type
    For plasterboards
  • Width [mm]
    68
  • Mounting hole diameter [mm]
    71
  • Weight [g]
    27
  • Number of bolts/screws
    2
  • Number of segments
    1
  • For modular equipment
    Not applicable
  • Exact material
    PP TPE
  • Color
    Orange
  • Material
    PP
  • Cover
    NO
  • Level of security
    IP30
  • Pieces in the package
    25
  • Type
    For attachments
  • Self-extinguishing
    Yes
  • Fire resistance
    Non-flammable
  • Fire resistance [°C]
    850
  • Attachment diameter [mm]
    60
  • PKWIU
    27.33.13.0
