UNIVERS Wall-mounted enclosure IP54/II 950x800x205 FP63SW2

Name: UNIVERS Wall-mounted enclosure IP54/II 950x800x205
Brand: HAGER
SKU: RMN048HAGE
Price: 3436.42 PLN
Availability: BackOrder

local index:

RMN048HAGE

Catalog number:

FP63SW2

EAN code:

3250612669332

UNIVERS Wall-mounted enclosure IP54/II 950x800x205

Click on the photo to enlarge

Manufacturer: HAGER

Depth [mm]: 205

Thickness [mm]: 1

Number of doors: 1

See full description

Price:

3 436,42 zł

gross / pcs.

(including VAT 23%)

up to 10 weeks

On request

Quantity pcs.

(multiplicity:

)

Add to inquiry

Add to clipboard

Ask about the product

Product description Technical data Manufacturer details Bulk packaging Files to download

Product description

Wall housing univers:

QuickSet mounting.

Characteristics of the series:

Cabinet systems are functional, not only as distribution switchgears (main power supply), but also as meter cabinets - they always form one, compact whole, while guaranteeing maximum safety.

Technical data

Depth [mm]

205
Number of doors

1
Protection class

II
Housing material

Steel plate
Family

UNIVERS
Width [mm]

750
Number of sections

3
Number of cable entries

6
PKWIU

27.12.40.0

Thickness [mm]

1
Number of locks

1
Color

White
Fixing

QuickSet
Level of security

IP54
Height [mm]

950
Number of rows for cameras

6
Lock type

T-Handle

Other technical data

Mounting method

Surface mounted
Cover model

Closed
Transparent cover/door

No
Nominal current (In)

250 A
Width

800 mm
Built-in depth

205 mm
Material plate thickness cabinet

1 mm
Colour

White
Number of modules

216
Width in number of modular spacings

36
Extension possible

Yes
Housing material

Steel
With mounting plate

No
Suitable for lightning protection

No
Protection class

II
Circuit integrity

None

Type of covering

Door
Type of door

Single
With lock

No
Height

950 mm
Depth

205 mm
Inner depth

130 mm
Material plate thickness door/cover

1 mm
RAL-number

9010
Number of rows

6
Number of openings for flange plates

6
Number of conduit inlets

6
Surface protection

Powder coating
Suitable for outdoor use

No
Degree of protection (IP)

IP54
Impact strength

IK09
Cover with overpressure release

No

Manufacturer details

Manufacturer

Hager Electro GmbH & Co KG
Address

DE 66440 Blieskastel Zum Gunterstal Niemcy
E-mail

wsparcie.klienta@hager.com

Bulk packaging

A kind of package	Karton	Paleta	Karton	Paleta
Quantity	1 pcs.	5 pcs.	1 pcs.	5 pcs.
Weight (kg)	25,100	150,500	25,100	150,500
Width (m)	0,210	0,820	0,210	0,820
Length (m)	1,000	1,140	1,000	1,140
Depth (m)	0,820	1,200	0,820	1,200
