Single-phase transformer TMM 200/A 230/24V 16224-9966

Índice local:
AUP013BREV
Número de catálogo:
16224-9966
Código EAN:
5907812712167
Fabricante: BREVE
Length [mm]: 96
number of phases: 1
Maximum ambient temperature [°C]: 40
Los más vendidos
Precio:
184,73 zł
gross / uds.
(IVA incluido 23%)
Precio más bajo a partir de 30 días antes del descuento: 184,73 zł gross
Precio del fabricante: 348,23 zł gross
Entrega en 3h
Accesible 2 uds.
Recogida en 1h
Cantidad uds.
(múltiple:
1
)
Añadir a solicitud de presupuesto
Añadir al portapapeles
Imprimir

Descripción del producto

Single-phase open (IP00) isolation or safety transformers, intended for general use and built-in in industrial or
electric power installations and devices.
I insulation class and IP00 protection, max. ambient temperature 40°C.
Made according to EN 61558-2-4, EN 61558-2-6.

Datos técnicos

  • Length [mm]
    96
  • Maximum ambient temperature [°C]
    40
  • Primary voltage [V]
    230
  • Mounting method
    For screws
  • Width [mm]
    100
  • Weight [kg]
    3.2
  • Mounting thread
    M4
  • Secondary current [A]
    8.3
  • PKWIU
    27.11.42.0
  • number of phases
    1
  • Power [VA]
    200
  • Secondary voltage [V]
    24
  • Level of security
    IP00
  • ambient temperature [°C]
    40
  • Height [mm]
    115
  • Insulation class
    b
  • No-load voltage [V]
    25.3

Otros datos técnicos

  • Built as safety transformer
    Yes
  • Built as energy saving transformer
    No
  • Secondary voltage 1
    24 ... - V
  • Type of insulation material according to IEC 85
    B
  • Width
    96 mm
  • Depth
    115 mm
  • Ring core
    No
  • Modular version
    No
  • Built as isolating transformer
    No
  • Primary voltage 1
    230 ... - V
  • Rated apparent power
    200 VA
  • Short-circuit-proof
    No
  • Height
    100 mm
  • Degree of protection (IP)
    IP00
  • Suitable for mounting on PCB
    No

Detalles del fabricante

  • Fabricante
    BREVE-TUFVASSONS Sp. z o.o.
  • Dirección
    93-347 Łódź Postępowa 25/27 Polska

Empaquetado a granel

una especie de paquete Paczka Karton
Cantidad 1 uds. 1 uds. 8 uds.
Peso (kg) 3,200 - 26,400
Ancho (m) 0,096 0,110 0,380
Longitud (m) 0,115 0,115 0,127
Profundidad (m) 0,100 0,095 0,233
