Single-phase transformer TMM 100/A 230/24V 16224-9988
local index:
AUP008BREV
Catalog No:
16224-9988
EAN code:
5907812711474
Price:
47,96 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Single-phase open (IP00) isolation or safety transformers, intended for general use and built-in in industrial or
electric power installations and devices.
I insulation class and IP00 protection, max. ambient temperature 40°C.
Made according to EN 61558-2-4, EN 61558-2-6.
electric power installations and devices.
I insulation class and IP00 protection, max. ambient temperature 40°C.
Made according to EN 61558-2-4, EN 61558-2-6.
Technical data
-
Length [mm]84
-
Maximum ambient temperature [°C]40
-
Primary voltage [V]230
-
Mounting methodFor screws
-
Width [mm]84
-
Primary winding [V]230
-
Mounting threadM4
-
Depth [mm]100
-
Power [VA]100
-
Secondary voltage [V]24
-
Level of securityIP00
-
Height [mm]74
-
Secondary winding [V]24
-
PKWIU27.11.42.0
Other technical data
-
Built as safety transformerYes
-
Built as energy saving transformerNo
-
Secondary voltage 124 ... - V
-
Type of insulation material according to IEC 85B
-
Width84 mm
-
Depth100 mm
-
Ring coreNo
-
Modular versionNo
-
Built as isolating transformerNo
-
Primary voltage 1230 ... - V
-
Rated apparent power100 VA
-
Short-circuit-proofNo
-
Height74 mm
-
Degree of protection (IP)IP00
-
Suitable for mounting on PCBNo
Manufacturer details
-
ManufacturerBREVE-TUFVASSONS Sp. z o.o.
-
Address93-347 Łódź Postępowa 25/27 Polska
-
