Single-phase transformer PSS 30 230/ 24V 16024-9997
local index:
AUP308BREV
Catalog No:
16024-9997
EAN code:
5907812710316
Price:
40,48 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Enclosed, safety or separation transformers, intended mainly for mounting on a T-35 rail.
Aesthetic housing with a spring-loaded handle significantly facilitates and speeds up mounting.
These are made in class II insulation and IP20 protection level (models with N series) or IP30, max. ambient temperature 40°C, insulation thermal class B (130°C).
Made according to EN 61558-2-4, EN 61558-2-6.
Aesthetic housing with a spring-loaded handle significantly facilitates and speeds up mounting.
These are made in class II insulation and IP20 protection level (models with N series) or IP30, max. ambient temperature 40°C, insulation thermal class B (130°C).
Made according to EN 61558-2-4, EN 61558-2-6.
Technical data
-
Depth [mm]63
-
Power [VA]thirty
-
Primary voltage [V]230
-
Mounting methodFor screws
-
Width [mm]110
-
Primary winding [V]230
-
Mounting threadM4
-
Maximum ambient temperature [°C]40
-
InstallationOn the TH-43 rail
-
Secondary voltage [V]24
-
Level of securityIP30
-
Height [mm]72
-
Secondary winding [V]24
-
PKWIU27.11.42.0
Other technical data
-
Built as safety transformerYes
-
Built as energy saving transformerNo
-
Secondary voltage 124 ... - V
-
Type of insulation material according to IEC 85B
-
Width72 mm
-
Depth63 mm
-
Ring coreNo
-
Modular versionYes
-
Built as isolating transformerNo
-
Primary voltage 1230 ... - V
-
Rated apparent power30 VA
-
Short-circuit-proofYes
-
Height110 mm
-
Degree of protection (IP)IP30
-
Suitable for mounting on PCBNo
Manufacturer details
-
ManufacturerBREVE-TUFVASSONS Sp. z o.o.
-
Address93-347 Łódź Postępowa 25/27 Polska
-
