W.1 SCHUKO socket 2P+Z IP55 white 47063512
local index:
MEB001BERK
Catalog No:
47063512
EAN code:
4011334390473
Price:
16,29 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
SCHUKO 2P+Z grounded socket-outlet, from the Berker W.1 series, which combines the functionality of an external electrical installation with an aesthetic appearance. The mechanisms achieve the IP55 degree of protection only when mounted with a surface-mounted housing or a frame for flush-mounting.
Technical data
-
Depth [mm]44
-
ColorWhite
-
MaterialPlastic
-
Rated voltage [V]230
-
TypeElectrical hermetic
-
Level of securityIP55
-
TypeRecessed Surface-mounted
-
Height [mm]71
-
Surface finishmatte
-
Terminal typeThreadless
-
Shutters of current pathsYes
-
For the frame systemYes
-
Exact materialThermoplastic
-
Number of sockets1
-
ShapeSquare
-
InstallationRecessed Surface-mounted
-
Rated current [A]16
-
FamilyW.1
-
Width [mm]71
-
Groundschuko
-
Degree of mechanical protectionIK05
-
BacklightNO
-
StandardEuropean
-
On the DATA keyNO
-
Lid colorSocket color
-
PKWIU27.33.13.0
Other technical data
-
ModelProtective contact CEE 7/3 / CEE 7/4 (type F)
-
Okrągły styk ochronnyNo
-
Number of active contacts (flat)0
-
With built-in USB power supplyNo
-
Number of modules (module system)0
-
Number of phases1
-
With hinged lidYes
-
Label space/information surfaceNo
-
RAL-number (similar)9010
-
LockableNo
-
Insulated mountingYes
-
With orientation lightingNo
-
Fault current protectionNo
-
Special power supplyNo special power supply
-
Type of fasteningMounting with screw
-
Material qualityThermoplastic
-
Surface protectionUntreated
-
Anti-bacterial treatmentNo
-
With loop through functionNo
-
Nominal current16 A
-
Frequency50 ... 60 Hz
-
Suitable for degree of protection (IP)IP55
-
Device width71 mm
-
Device depth44 mm
-
Protective contactYes
-
Number of active contacts (round)2
-
With signal lampNo
-
Number of units1
-
Number of socket outlets switchable0
-
Connection typePush-in clamp
-
With enhanced contact protectionYes
-
ColourWhite
-
TransparentNo
-
Eject-mechanismNo
-
With function lightingNo
-
Over voltage protectionNo
-
With miniature fuseNo
-
Mounting methodSurface mounted
-
MaterialPlastic
-
Halogen freeYes
-
Surface finishingMatt
-
With on/off switchNo
-
Rotated central insertNo
-
Nominal voltage250 V
-
Rated fault current0 mA
-
Impact strengthIK05
-
Device height71 mm
-
Min. depth of built-in installation box0 mm
Manufacturer details
-
ManufacturerHAGER POLO Sp. z o. o.
-
Address43-100 Tychy Fabryczna 10
-
E-mail
-
Tax identification number6460015532
-
GLN5900009931532
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 1 pcs. | 36 pcs. | 1152 pcs. |
| Weight (kg) | 0,070 | 0,075 | 3,140 | 123,480 |
| Width (m) | 0,071 | 0,080 | 0,300 | 0,800 |
| Length (m) | 0,044 | 0,070 | 0,225 | 1,050 |
| Depth (m) | 0,071 | 0,080 | 0,400 | 1,200 |
