246728
0
W.1 Earthed socket 2P+Z IP55 grey 6768803515
local index:
MEB041BERK
Catalog No:
6768803515
EAN code:
4011334390503
Price:
12,93 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Earthed socket, from the Berker W.1 series, which combines the functionality of an external electrical installation with an aesthetic appearance. The mechanisms achieve the IP55 degree of protection only when mounted with a surface-mounted housing or a flush-mounted frame.
- 2P+E
- 2-pole
- with lockable cover, manually locked
- with plug-in terminals
Technical data
-
Number of sockets1
-
ShapeSquare
-
InstallationRecessed Surface-mounted
-
Rated current [A]16
-
FamilyW.1
-
Width [mm]71
-
GroundHurt
-
Degree of mechanical protectionIK05
-
Accurate colordark grey
-
Mounting depth [mm]44
-
Shutters of current pathsYes
-
For the frame systemYes
-
Exact materialThermoplastic
-
ColorGray
-
MaterialPlastic
-
Rated voltage [V]230
-
TypeElectrical hermetic
-
Level of securityIP55
-
TypeRecessed Surface-mounted
-
Height [mm]71
-
Surface finishmatte
-
BacklightNO
-
StandardEuropean
-
On the DATA keyNO
-
Lid colorSocket color
-
PKWIU27.33.13.0
Other technical data
-
ModelProtective contact CEE 7/3 / CEE 7/4 (type F)
-
Okrągły styk ochronnyYes
-
Number of active contacts (flat)0
-
With built-in USB power supplyNo
-
Number of socket outlets switchable0
-
Connection typePush-in clamp
-
With enhanced contact protectionYes
-
ColourGrey
-
TransparentNo
-
Eject-mechanismNo
-
With function lightingNo
-
Over voltage protectionNo
-
With miniature fuseNo
-
Mounting methodSurface mounted
-
MaterialPlastic
-
Halogen freeYes
-
Surface finishingMatt
-
With on/off switchNo
-
Rotated central insertNo
-
Nominal voltage250 V
-
Suitable for degree of protection (IP)IP55
-
Device width71 mm
-
Device depth44 mm
-
Protective contactYes
-
Number of active contacts (round)2
-
With signal lampNo
-
Number of units1
-
Number of phases1
-
With hinged lidYes
-
Label space/information surfaceNo
-
RAL-number (similar)7011
-
LockableNo
-
Insulated mountingYes
-
With orientation lightingNo
-
Fault current protectionNo
-
Special power supplyNo special power supply
-
Type of fasteningMounting with screw
-
Material qualityThermoplastic
-
Surface protectionUntreated
-
Anti-bacterial treatmentNo
-
With loop through functionNo
-
Nominal current16 A
-
Frequency50 ... 60 Hz
-
Impact strengthIK05
-
Device height71 mm
-
Min. depth of built-in installation box0 mm
Bulk packaging
| A kind of package | Karton | Pakiet | Paleta | |
| Quantity | 1 pcs. | 10 pcs. | 40 pcs. | 1280 pcs. |
| Weight (kg) | 0,059 | 0,690 | 3,200 | 125,400 |
| Width (m) | 0,071 | 0,175 | 0,300 | 0,800 |
| Length (m) | 0,044 | 0,095 | 0,225 | 1,050 |
| Depth (m) | 0,071 | 0,230 | 0,400 | 1,200 |
