SUNO - Flat socket 2P+Z - 16 A - with USB Type-C - 1.5 A - automatic terminals - with shutter, Black 721489

Index local:
MEU006LEGR
Numéro de catalogue:
721489
Code EAN:
3414972046725
Producteur: LEGRAND
Prix:
173,76 zł
gross / pcs.
(y compris la TVA 23%)
2 semaines
Sur commande
Quantité pcs.
(plusieurs:
1
)
Ajouter à la demande de devis
Ajouter au presse-papiers
Imprimer

Données techniques

Autres données techniques

  • Model
    Earthing pin
  • Protective contact
    Round
  • Number of active contacts (flat)
    0
  • Assembly arrangement
    Basic element with central cover plate
  • Number of ports USB-A
    0
  • Number of socket outlets
    1
  • Number of modules (module system)
    2
  • Number of phases
    1
  • Connection type
    Push-in clamp
  • With enhanced contact protection
    Yes
  • Colour
    Black
  • Transparent
    No
  • Eject-mechanism
    No
  • With function lighting
    No
  • Over voltage protection
    No
  • With miniature fuse
    No
  • Mounting method
    Flush-mounted
  • Material
    Plastic
  • Halogen free
    Yes
  • Surface finishing
    Matt
  • With loop through function
    No
  • Colour of switch operator
    Black
  • Nominal current
    16 A
  • Frequency
    50 ... 60 Hz
  • Impact strength
    IK04
  • Device height
    72.9 mm
  • Min. depth of built-in installation box
    40 mm
  • Compatible with Amazon Alexa
    No
  • IFTTT support available
    No
  • With built-in bluetooth speaker
    No
  • Concurrently switching neutral conductor
    No
  • Number of active contacts (round)
    2
  • Number of active contacts (square)
    0
  • With signal lamp
    No
  • Number of ports USB-C
    1
  • Gniazda z izolacją fazową
    No
  • Number of socket outlets switchable
    0
  • Imprint/indication
    None
  • With hinged lid
    No
  • Label space/information surface
    No
  • Metallic colour
    No
  • Lockable
    No
  • Insulated mounting
    No
  • With orientation lighting
    No
  • Fault current protection
    No
  • Special power supply
    Other
  • Type of fastening
    Mounting with claw and screw
  • Material quality
    Thermoplastic
  • Surface protection
    Lacquered
  • Anti-bacterial treatment
    No
  • With on/off switch
    No
  • Rotated central insert
    No
  • Nominal voltage
    250 V
  • Suitable for degree of protection (IP)
    IP20
  • Device width
    72.9 mm
  • Device depth
    41.6 mm
  • Compatible with Apple HomeKit
    No
  • Compatible with Google Assistant
    No
  • With Wi-Fi signal repeater
    No
  • For heavy conditions according to VDE
    No

Détails du fabricant

  • Producteur
    Legrand Polska Sp. z o.o.
  • Adresse
    57-200 Ząbkowice Śląskie Waryńskiego 20 Polska

Emballage en vrac

Une sorte de paquet Pudełko Karton Paleta
Quantité 5 pcs. 100 pcs. 500 pcs.
poids (kg) 0,458 9,681 48,405
Volume (m3) 0,002 0,048 0,415
Largeur (m) 0,093 0,398 1,200
Longueur (m) 0,115 0,202 0,346
Profondeur (m) 0,193 0,598 1,000
