el12 Connecting cables and wires Cable terminals Cu tips Tubular ring cable terminal KOR 16/10 10 pcs
el12 sale Create strong connections - ERGOM Tubular ring cable terminal KOR 16/10 10 pcs
Tubular ring cable terminal KOR 16/10 10 pcs

Click on the photo to enlarge

Tubular ring cable terminal KOR 16/10 10 pcs
ERGOM

Tubular ring cable terminal KOR 16/10 10 pcs E11KM-01020103102

local index:
TCC338ERGO
Catalog No:
E11KM-01020103102
Price:
6,94 €
gross / pkg.
including VAT 23%
Availability:
Check availability in branches
In warehouses 137 pkg.
Delivery:
From 3,47 € (prepaid courier) Details
Estimated delivery time:
DHL, Inpost 1-3 working days

Delivery in 3h

Pickup in 1h

Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pkg.
It is not possible to add more of this product to the cart. Goods at a promotional price can only be purchased in the quantity available in stock.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details
Go to section:
Product description Technical data

Product description

KOR 16/10 tubular ring cable lug from the manufacturer ERGOM. The product catalog number is E11KM -01020103102.

  • Cross section rm/sm [mm²]: 16.
  • Number of crimps - wide: 1.
  • Number of crimps - narrow: 2.
  • Socket number: 8.
  • Attention! Sector wires (sm) must be reformed “round”.
    • < li>Cu ring terminal in standard version with galvanic tin coating.
  • Description of the wire cross-section and clamp size on the fin surface.
  • Popular version for responsible applications.
    • < /ul>
Print the product sheet Report an error

Technical data

  • Length to center of hole [mm]
    29.5
  • Material
    Copper
  • Flange width [mm]
    17
  • Outer diameter [mm]
    8.5
  • Screw hole
    M10
  • Sleeve length [mm]
    13
  • Type
    Oczkowa
  • Inner diameter [mm]
    5.5
  • cross section [mm²]
    16
  • Coverage
    Tin plated

Other technical data

  • Bolt dimension (metric)
    10
  • Slender flange model
    yes
  • With sight-hole
    no
  • Surface protection
    Tinned
  • Flange shape
    Ring shape
  • Insulated
    no
  • Material
    Copper
  • Nominal cross section
    16 mm²
