Tinned Cu tubular terminal DIN 6mm² metric thread M6 10 pcs 290404/10
local index:
TCC0F0HAUP
Catalog No:
290404/10
EAN code:
4011923601775
Price:
9,30 €
gross / pkg.
(including VAT 23%)
0,93 € gross/pcs.
Delivery in 3h
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Tubular terminals thick-walled „SmallPack“ DIN 46235:
- material: 99.9% electrolytic copper,
- surface: tin-plated.< /li>
Technical data
-
Sleeve length [mm]10
-
Flange width [mm]8.5
-
Hole diameter [mm]6.4
-
Outer diameter [mm]5.5
-
Wire cross-section [mm²]6
-
ThreadM6
-
Pieces in the package10
-
Inner diameter [mm]3.8
-
cross section [mm²]6
Other technical data
-
Bolt dimension (metric)6
-
Code digit5
-
Number of mounting holes1
-
Nominal cross section6 mm²
Manufacturer details
-
ManufacturerHAUPA GmbH
-
Address42857 Remscheid Lange Straße 40 Niemcy
-
