Tinned Cu tubular terminal DIN 35mm² metric thread M8 10 pcs 290434/10
local index:
TCC0F9HAUP
Catalog No:
290434/10
EAN code:
4011923601843
Price:
53,17 €
gross / pkg.
(including VAT 23%)
5,32 € gross/pcs.
Delivery in 3h
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Tubular terminals thick-walled „SmallPack“ DIN 46235:
- material: 99.9% electrolytic copper,
- surface: tin-plated.< /li>
Technical data
-
Sleeve length [mm]20.2
-
Flange width [mm]17
-
Hole diameter [mm]6.4
-
Outer diameter [mm]12.5
-
Wire cross-section [mm²]35
-
ThreadM8
-
Pieces in the package10
-
Inner diameter [mm]8.2
-
cross section [mm²]35
Other technical data
-
Bolt dimension (metric)8
-
Code digit12
-
Number of mounting holes1
-
Nominal cross section35 mm²
