Tinned Cu tubular terminal DIN 35mm² metric thread M10 10 pcs 290436/10

local index:
TCC0G0HAUP
Catalog No:
290436/10
EAN code:
4011923601850
Manufacturer: HAUPA
Sleeve length [mm]: 20
Thread: M10
Flange width [mm]: 19
Price:
53,68 €
gross / pkg.
(including VAT 23%)
5,37 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Tubular terminals thick-walled „SmallPack“ DIN 46235:

  • material: 99.9% electrolytic copper,
  • surface: tin-plated.< /li>

Technical data

  • Sleeve length [mm]
    20
  • Flange width [mm]
    19
  • Hole diameter [mm]
    10.5
  • Outer diameter [mm]
    12.5
  • Wire cross-section [mm²]
    35
  • Thread
    M10
  • Pieces in the package
    10
  • Inner diameter [mm]
    8.2
  • cross section [mm²]
    35

Other technical data

  • Bolt dimension (metric)
    10
  • Code digit
    12
  • Number of mounting holes
    1
  • Nominal cross section
    35 mm²
