Click on the photo to enlarge

HAUPA

Tinned Cu connector DIN 10 mm² 291126

local index:
TCC544HAUP
Catalog No:
291126
EAN code:
4011923093686
Price:
28,07 €
gross / pkg.
including VAT 23%
Availability:
up to 2 weeks (business days)
Delivery:
From 3,49 € (prepaid courier) Details
Quantity:
Goods at a promotional price can only be purchased in the quantity available in stock pkg.
Delivery methods:
Metody dostawy
details
Payment methods:
Metody płatności
details

Product description

Press connector for copper wires

Technical data

  • Length [mm]
    21
  • Pieces in the package
    100
  • Surface protection
    tin plating
  • Package height [mm]
    7
  • Package weight [kg]
    0.3
  • Number of branches
    2
  • cross section [mm²]
    10
  • Wire cross-section [mm²]
    10
  • Model
    DIN-compliant version
  • Outer diameter [mm]
    7
  • Connection type
    Crimp connector
  • Package width [mm]
    7
  • Package length [mm]
    21
  • Voltage range
    Up to 10 kV
  • For unloaded connections
    NO

Other technical data

  • Nominal cross section
    10 ... 10 mm²
  • Sleeve form
    Long
  • Suitable for stranded conductors
    yes
  • Suitable for high temperatures (to 650 °C)
    no
  • Suitable for round conductors
    yes
  • Material
    Copper
  • Voltage level
    Up to 10 kV
  • Number of branches
    2
  • Oil stop/centre bar
    no
  • Model
    DIN-version
  • Suitable for solid conductors
    no
  • Suitable for fine strand conductors
    no
  • Suitable for insulated varnish
    no
  • Suitable for flat conductors
    no
  • Insulation
    None
  • Type of connection
    Percussion connector
  • For pull protected connections
    no
