terminal AL DIN 240M16 12 pcs 292948

local index:
TCA063HAUP
Catalog No:
292948
EAN code:
4011923176297
Manufacturer: HAUPA
Length to center of hole [mm]: 116
Type: Oczkowa
Pieces in the package: 12
Price:
58,18 €
gross / pkg.
(including VAT 23%)
4,85 € gross/pcs.
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Crimp cable lugs for aluminum conductors

Technical data

  • Length to center of hole [mm]
    116
  • Pieces in the package
    12
  • Hole diameter [mm]
    17
  • Package height [mm]
    40
  • Package weight [kg]
    0.15
  • cross section [mm²]
    240
  • Type
    Oczkowa
  • Mesh diameter [mm]
    45
  • Outer diameter [mm]
    21
  • Package width [mm]
    60
  • Package length [mm]
    100
  • Wire cross-section [mm²]
    240

Other technical data

  • Bolt dimension (metric)
    16
  • Suitable for Al/St-cables
    No
  • Material
    Aluminium
  • Longitudinal sealed
    No
