LA 120 aluminum tubular cable connector E12KA-01100100850
local index:
TCT039ERGO
Catalog No:
E12KA-01100100850
Price:
3,31 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
LA aluminum tubular cable connector:
- Clamped part according to DIN
- For connecting wires on the so-called “contact”
- mechanically unloaded
- description of the cable cross-section, number of the clamping die on the surface of the crimped part
- the embossment in the middle guarantees insertion of the cable core to the required length
Technical data
-
Length [mm]105
-
cross section [mm²]120
-
Stranded conductor cross-section [mm²]120
-
PKWIU27.33.13.0
-
MaterialAluminum
-
Solid conductor cross-section [mm²]150
-
CoverageNo cover
Other technical data
-
Cross section formOkrągły linkowy/ sektorowy linkowy
-
Connection as copper boltNo
-
For pull protected connectionsYes
-
Suitable for Aldrey-cablesNo
-
Al - przekrój znamionowy120 mm²
-
MaterialAluminium
-
Suitable for Al/St-cablesNo
-
Oil stop/centre barNo
Bulk packaging
| A kind of package | Sztuka |
| Quantity | 50 pcs. |
| Weight (kg) | 0,080 |
| Width (m) | 0,040 |
| Length (m) | 0,030 |
| Depth (m) | 0,030 |
