KLD 120 connector E11KM-02060100800

local index:
TCC207ERGO
Catalog No:
E11KM-02060100800
Manufacturer: ERGOM
short name: KLD 120
Pieces in the package: 50
cross section [mm²]: 120
Price:
273,60 €
gross / pkg.
(including VAT 23%)
5,47 € gross/pcs.
Delivery in 3h
up to a week (working days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Add to clipboard
Print

Product description

KLD 120 connector

Technical data

  • short name
    KLD 120
  • cross section [mm²]
    120
  • PKWIU
    27.33.13.0
  • Pieces in the package
    50
  • Wire cross-section [mm²]
    120

Other technical data

  • Nominal cross section
    0 ... 120 mm²
  • Sleeve form
    Long
  • Suitable for stranded conductors
    Yes
  • Suitable for high temperatures (to 650 °C)
    No
  • Suitable for round conductors
    Yes
  • Material
    Copper
  • Insulation
    None
  • Type of connection
    Percussion connector
  • Oil stop/centre bar
    No
  • Model
    DIN-version
  • Suitable for solid conductors
    No
  • Suitable for fine strand conductors
    Yes
  • Suitable for insulated varnish
    No
  • Suitable for flat conductors
    No
  • Surface protection
    Tinned
  • Voltage level
    Up to 10 kV
  • For pull protected connections
    Yes

Manufacturer details

Bulk packaging

A kind of package Sztuka
Quantity 1 pkg.
Weight (kg) 4,880
Width (m) 0,195
Length (m) 0,145
Depth (m) 0,097
