Cu 2.5 thin-walled connector 200 pcs 294202

local index:
TCC858HAUP
Catalog No:
294202
EAN code:
4011923489267
Manufacturer: HAUPA
Length [mm]: 22
Model: Standard execution
Pieces in the package: 200
Price:
33,48 €
gross / pkg.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pkg.
(multiplicity:
1
)
Print

Product description

Press connector for copper wires

Technical data

  • Length [mm]
    22
  • Pieces in the package
    200
  • Surface protection
    tin plating
  • Package height [mm]
    4.5
  • Package weight [kg]
    0.08
  • Voltage range
    Up to 10 kV
  • For unloaded connections
    NO
  • Model
    Standard execution
  • Outer diameter [mm]
    4.3
  • Connection type
    Crimp connector
  • Package width [mm]
    4.5
  • Package length [mm]
    22
  • cross section [mm²]
    2.5
  • Wire cross-section [mm²]
    2.5

Other technical data

  • Nominal cross section
    2.5 ... 2.5 mm²
  • Sleeve form
    Short
  • Suitable for stranded conductors
    yes
  • Suitable for high temperatures (to 650 °C)
    no
  • Suitable for round conductors
    yes
  • Material
    Copper
  • Voltage level
    Up to 10 kV
  • For pull protected connections
    no
  • Model
    Standard version
  • Suitable for solid conductors
    no
  • Suitable for fine strand conductors
    yes
  • Suitable for insulated varnish
    no
  • Suitable for flat conductors
    no
  • Insulation
    None
  • Type of connection
    Percussion connector
  • Oil stop/centre bar
    no
