Name: SecurityNET U/UTP cat. 6 cable, external, gelled PE, 500 m
Brand: SECURITYNET
SKU: KRD008CICQ
Price: 0.70 PLN
Availability: InStock

Other technical data

Conductor material

Copper
AWG size

23
Number of cores

8
Material core insulation

Other
Core identification according to HD 308 S2

Yes
Screen over stranding element

None
Screen over stranding

None
Radial water blocking cable

Yes
Approved type of underground installation

Other
Material outer sheath

Other
Colour outer sheath

Black
Material armouring

Other
Reaction-to-fire according to EN 13501-6: Class

Fca
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles

None
Halogen free according to EN IEC 60754-2

No
Oil resistant according to EN IEC 60811-404

No
Min. permitted bending radius, moving application with forced guidance

64 mm
Min. permitted bending radius, stationary application/permanent installation

51 mm
Permitted cable outer temperature after assembling without vibration

0 ... 60 °C
NVP value

62 %
Certified for shipboard application

No
Suitable as computer data cable

Yes
Weight

60

Conductor surface

Bare
Conductor category

Class 1 = solid
Stranding element

Pairs
Specification core insulation

Polyethylene (PE)
Core identification

Colour
Stranding

None
Longitudinal water blocking cable

Yes
Suitable for underground installation

Yes
Protective sheath

Al/PE
Specification material outer sheath

Polyethylene (PE)
Armouring/reinforcement

None
Cable geometry

Round
Reaction-to-fire according to EN 13501-6: Smoke production

None
Reaction-to-fire according to EN 13501-6: Acidity

None
Low smoke according to EN IEC 61034-2

No
Outer diameter approx.

6.4 mm
Min. permitted bending radius, moving application/free movement

64 mm
Permitted cable outer temperature during assembling/handling

-40 ... 60 °C
Category

6
UV resistant

Yes
Suitable as telephone cable

Yes
Suitable as signalling cable

Yes

A kind of package		Bęben
Quantity	1 m.	1 m.
Weight (kg)	25,600	-

SecurityNET U/UTP cat. 6 cable, external, gelled PE, 500 m SEC6UTPG
