SecurityNET U/UTP cable cat.5e CU LSZH, 305m SEC5EUTPLSZH-DCA
Místní index:
KRD013CICQ
Katalogové číslo.:
SEC5EUTPLSZH-DCA
EAN kód:
5904169103815
Výrobce:
SECURITYNET
Cena:
2,30 zł
gross / bm.
(včetně DPH 23%)
Vyzvednutí za 1h
Množství bm.
(vícenásobné:
1
)
Přidat do žádosti o cenovou nabídku
Přidat do schránky
Vytisknout
Dotaz na výrobek
Technické údaje
Další technické údaje
-
Conductor materialCopper
-
Diameter conductor0.5 mm
-
Conductor categoryClass 1 = solid
-
Number of stranding elements1
-
Material core insulationOther
-
Core identification according to HD 308 S2Yes
-
Screen over stranding elementNone
-
Screen over strandingNone
-
Radial water blocking cableYes
-
Approved type of underground installationOther
-
Material outer sheathOther
-
Colour outer sheathWhite
-
Material armouringOther
-
Low smoke according to EN IEC 61034-2Yes
-
Reaction-to-fire according to EN 13501-6: ClassDca
-
Reaction-to-fire according to EN 13501-6: Flaming droplets/particlesd1
-
Oil resistant according to EN IEC 60811-404No
-
Min. permitted bending radius, moving application with forced guidance50 mm
-
Min. permitted bending radius, stationary application/permanent installation40 mm
-
Permitted cable outer temperature after assembling without vibration-20 ... 60 °C
-
NVP value68 %
-
Suitable as telephone cableYes
-
Suitable as signalling cableYes
-
Conductor surfaceBare
-
AWG size24
-
Number of cores8
-
Stranding elementPairs
-
Specification core insulationPolyethylene (PE)
-
Core identificationColour
-
StrandingNone
-
Longitudinal water blocking cableNo
-
Suitable for underground installationNo
-
Protective sheathOther
-
Specification material outer sheathPolyethylene (PE)
-
Armouring/reinforcementNone
-
Cable geometryRound
-
Halogen free according to EN IEC 60754-2Yes
-
Reaction-to-fire according to EN 13501-6: Smoke productions1
-
Reaction-to-fire according to EN 13501-6: Aciditya1
-
Outer diameter approx.5 mm
-
Min. permitted bending radius, moving application/free movement50 mm
-
Permitted cable outer temperature during assembling/handling0 ... 50 °C
-
Category5E
-
Certified for shipboard applicationNo
-
Suitable as computer data cableYes
-
Weight29.5 kg/km
Podrobnosti o výrobci
-
VýrobceC&C Partners Sp. z o.o.
-
Adresa64-100 Leszno 17 Stycznia 119, 121 Polska
-
E-mail
Velkoobjemová balení
| Typ obalu | Karton | Paleta | Paleta | Karton |
| Množství | 305000 bm. | 16470000 bm. | 13725000 bm. | 305 bm. |
| Hmotnost (kg) | 9,000 | 511,000 | 429,000 | - |
| Šířka (m) | 0,350 | 1,100 | 1,100 | - |
| Délka (m) | 0,350 | 1,100 | 1,100 | - |
| Hloubka (m) | 0,210 | 1,400 | 1,200 | - |
