SecurityNET U/UTP 200MHz cat. 5e PVC cable 305m SEC5EUTP

Indice locale:
KRE017CICQ
Numero di catalogo:
SEC5EUTP
Codice EAN:
5904169100074
Produttore: SECURITYNET
Prezzo:
1,83 zł
gross / metro
(inclusa IVA 23%)
fino a 2 settimane
Su ordinazione
Quantità metro
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa

Dati tecnici

Altri dati tecnici

  • Conductor material
    Copper
  • Diameter conductor
    0.5 mm
  • AWG size
    24
  • Number of cores
    8
  • Stranding element
    Pairs
  • Specification core insulation
    Polyethylene (PE)
  • Core identification
    Colour
  • Stranding
    None
  • Longitudinal water blocking cable
    No
  • Suitable for underground installation
    No
  • Protective sheath
    Polyvinyl chloride (PVC)
  • Specification material outer sheath
    Other
  • Armouring/reinforcement
    None
  • Cable geometry
    Round
  • Halogen free according to EN IEC 60754-2
    No
  • Reaction-to-fire according to EN 13501-6: Smoke production
    None
  • Reaction-to-fire according to EN 13501-6: Acidity
    None
  • Outer diameter approx.
    5 mm
  • Min. permitted bending radius, moving application/free movement
    50 mm
  • Permitted cable outer temperature during assembling/handling
    -20 ... 60 °C
  • Category
    5E
  • Certified for shipboard application
    No
  • Suitable as computer data cable
    Yes
  • Weight
    29.5 kg/km
  • Conductor surface
    Bare
  • Nominal cross section conductor
    0.196 mm²
  • Conductor category
    Class 1 = solid
  • Number of stranding elements
    1
  • Material core insulation
    Other
  • Core identification according to HD 308 S2
    Yes
  • Screen over stranding element
    None
  • Screen over stranding
    None
  • Radial water blocking cable
    Yes
  • Approved type of underground installation
    Other
  • Material outer sheath
    Polyvinyl chloride (PVC)
  • Colour outer sheath
    Grey
  • Material armouring
    Other
  • Low smoke according to EN IEC 61034-2
    No
  • Reaction-to-fire according to EN 13501-6: Class
    Eca
  • Reaction-to-fire according to EN 13501-6: Flaming droplets/particles
    None
  • Oil resistant according to EN IEC 60811-404
    No
  • Min. permitted bending radius, moving application with forced guidance
    50 mm
  • Min. permitted bending radius, stationary application/permanent installation
    40 mm
  • Permitted cable outer temperature after assembling without vibration
    0 ... 60 °C
  • NVP value
    69 %
  • Suitable as telephone cable
    Yes
  • Suitable as signalling cable
    Yes

Dettagli del produttore

  • Produttore
    C&C Partners Sp. z o.o.
  • Indirizzo
    64-100 Leszno 17 Stycznia 119, 121 Polska

Imballaggio sfuso

Una specie di pacchetto Karton Paleta Paleta Karton
Quantità 305000 metro 16470000 metro 13725000 metro 305 metro
Peso (kg) 9,000 506,000 425,000 -
Larghezza (m) 0,350 1,100 1,100 -
Lunghezza (m) 0,350 1,100 1,100 -
Profondità (m) 0,210 1,400 1,200 -
