Flexible cable 4X0.5 black numbered cores 10553

Místní index:
KEC120HELU
Katalogové číslo.:
10553
EAN kód:
4060892003318
Výrobce: HELUKABEL
Number of veins: 4
Color: Black
Vein material: Copper
objemné produkt
Cena:
5,09 zł
gross / bm.
(včetně DPH 23%)
Dodání do 3 hodin
Výrobek na individuální žádost
Vyzvednutí za 1h
Množství bm.
(vícenásobné:
1
)
Přidat do žádosti o cenovou nabídku
Vytisknout

Popis produktu

Used for medium mechanical loads for flexible connections where there are no tensile stresses. Usually installed in dry, damp and wet rooms, and outdoors (permanently installed). It can be laid directly in the ground when the thickness of the outer diameter is equal to or greater than 18 mm. Used in the engineering and metallurgical industries, for control, signaling and measurements at production lines, internal installations, air-conditioning installations, in metallurgy and steelworks. The veins are numbered in such a way that even a slight exposure of the outer dura allows the location of the vein to avoid confusion, the markings are underlined. A protective vein located close to the outer sheath. Outer tire made of special black PVC, UV-resistant. The cable is mainly used in the countries of Southern Europe, Eastern Europe and Arab countries. CE = The product complies with the requirements of the Low Voltage Directive 2006/95/EC.

Technické údaje

  • Number of veins
    4
  • Vein material
    Copper
  • Vein designation
    numbered
  • Core
    Cord
  • Nominal cross section [mm2]
    5
  • Insulation material
    PVC
  • Color
    Black
  • Rated voltage [V]
    300/500
  • Core cross-section [mm²]
    0.5
  • Outer diameter [mm]
    7.2
  • Accurate color
    RAL 9005
  • PKWIU
    27.32.13.0

Podrobnosti o výrobci

  • Výrobce
    HELUKABEL Polska Sp. z o.o.
  • Adresa
    96-325 Radziejowice Krze Duże 2 Polska
