el12 Automation Relays and drivers Time relays

Time relay RPC-2MA-UNI 2P 12...240 V AC/DC 8 A / 250 V AC 863183

local index:
APC048RELP
Catalog number:
863183
EAN code:
5900005230271
Time relay RPC-2MA-UNI 2P 12...240 V AC/DC 8 A / 250 V AC
Time relay RPC-2MA-UNI 2P 12...240 V AC/DC 8 A / 250 V AC

Click on the photo to enlarge

Manufacturer: RELPOL
Price:
220,35 zł
gross / pcs.
(including VAT 23%)
up to 2 weeks
On request
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print
Technical data Manufacturer details Files to download

Technical data

  • PKWIU
    27.33.13.0

Other technical data

  • Type of electric connection
    Screw connection
  • Pluggable on auxiliary contact block
    No
  • Function delay on de-energization
    Yes
  • Function floating contact on de-energization
    Yes
  • Function pulse shaping
    Yes
  • Function flashing, starting with pulse, fixed time
    Yes
  • Clock function, starting with pulse, variable
    Yes
  • Remote operation possible
    No
  • Rated control supply voltage AC 50 Hz
    12 ... 240 V
  • Rated control supply voltage DC
    12 ... 240 V
  • Number of outputs, undelayed, normally closed contact
    0
  • Number of outputs, undelayed, change-over contact
    2
  • Number of outputs, delayed, normally open contact
    0
  • Outputs, reversible delayed/undelayed
    No
  • Nominal current
    16 A
  • Height
    90 mm
  • Suitable for DIN rail (top hat rail) mounting
    Yes
  • Function delay-on energization
    Yes
  • Function floating contact on energization
    Yes
  • Function star-delta
    No
  • Function flashing, starting with pause, fixed time
    Yes
  • Clock function, starting with pause, variable
    Yes
  • Time range
    0.1 ... 864000 s
  • Suitable as remote control
    No
  • Rated control supply voltage AC 60 Hz
    12 ... 240 V
  • Voltage type for actuating
    AC/DC
  • Number of outputs, undelayed, normally open contact
    0
  • Number of outputs, delayed, normally closed contact
    0
  • Number of outputs, delayed, change-over contact
    2
  • With semiconductor output
    No
  • Width
    17.5 mm
  • Depth
    64.5 mm
