Switch disconnector, 63A, ZP-A63/3 284908
local index:
ALB031MOEL
Catalog No:
284908
EAN code:
4015082849085
Price:
49,18 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print
Ask about the product
Product description
ZP-A
• Possibility of adding auxiliary contacts, shunt and undervoltage releases
• Short-circuit strength with back-up fuse 40 A gG – 3 kA (U = 240V)
• Possibility of adding auxiliary contacts, shunt and undervoltage releases
• Short-circuit strength with back-up fuse 40 A gG – 3 kA (U = 240V)
Technical data
-
Number of poles3
-
Rated current [A]63
Other technical data
-
Switching functionOff switch
-
Number of contacts as normally closed contact3
-
Number of poles3
-
Rated voltage400 V
-
Rated switching capacity0 kA
-
Voltage typeAC
-
With signal lampNo
-
Width in number of modular spacings3
-
Degree of protection (IP)IP40
-
Number of contacts as normally open contact3
-
Number of contacts as change-over contact0
-
Rated current63 A
-
Min. rated voltage230 V
-
Short-circuit breaking capacity (Icw)3 kA
-
Wymuszone otwarcie styków (zgodnie z DIN VDE 0113)No
-
Max. lamp power0 W
-
Built-in depth60 mm
Manufacturer details
-
ManufacturerEaton Electric Sp. z o.o.
-
Address80-299 Gdańsk Galaktyczna 30 Polska
-
E-mail
Bulk packaging
| A kind of package | Skrzynia | Karton | Skrzynia | Karton |
| Quantity | 1 pcs. | 40 pcs. | 1 pcs. | 40 pcs. |
| Weight (kg) | 0,285 | 11,400 | 0,285 | 11,400 |
| Volume (m3) | 0,000 | 0,016 | 0,000 | 0,016 |
| Width (m) | 0,086 | 0,180 | 0,086 | 0,180 |
| Length (m) | 0,055 | 0,385 | 0,055 | 0,385 |
| Depth (m) | 0,075 | 0,230 | 0,075 | 0,230 |
