Switch disconnector, 63A, ZP-A63/1 284906

local index:
ALB033MOEL
Catalog No:
284906
EAN code:
4015082849061
Manufacturer: EATON
Rated current [A]: 63
Price:
18,04 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
12
)
Add to clipboard
Print

Product description

Switch disconnector, 63A, ZP-A63/1

Technical data

  • Rated current [A]
    63

Other technical data

  • Switching function
    Off switch
  • Number of contacts as normally closed contact
    1
  • Number of poles
    1
  • Rated voltage
    400 V
  • Rated switching capacity
    0 kA
  • Voltage type
    AC
  • With signal lamp
    No
  • Width in number of modular spacings
    1
  • Degree of protection (IP)
    IP40
  • Number of contacts as normally open contact
    1
  • Number of contacts as change-over contact
    0
  • Rated current
    63 A
  • Min. rated voltage
    230 V
  • Short-circuit breaking capacity (Icw)
    3 kA
  • Wymuszone otwarcie styków (zgodnie z DIN VDE 0113)
    No
  • Max. lamp power
    0 W
  • Built-in depth
    60 mm

Bulk packaging

A kind of package Skrzynia Karton Karton
Quantity 1 pcs. 12 pcs. 120 pcs.
Weight (kg) 0,095 1,140 11,400
Volume (m3) 0,000 0,001 0,016
Width (m) 0,020 0,086 0,180
Length (m) 0,085 0,218 0,385
Depth (m) 0,077 0,075 0,230
