Remote drive, 24-30VDC, standard 115393

local index:
ALA470MOEL
Catalog No:
115393
EAN code:
4015081151257
Manufacturer: EATON
Type of control voltage: AC
Price:
491,23 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Optional accessories for the NZM range of circuit breakers include a wide range of devices suitable for international use. Installation is flexible and easy thanks to the modular functional groups. Notes: For remote control of circuit breakers and disconnectors. Switching on/off and reset via continuous and pulse contact. Possibility of manual control on site. Closing in the 0 position of the remote operator with 3 shackle closures (shackle thickness: 4-8mm). Slider to set automatic or manual operation. number of auxiliary switch contacts: 2 normal auxiliary switches, 1 trip auxiliary switch. Cannot be combined with PN disconnectors. Cannot be combined with mechanical locking. Applicable to: NZM2(-4), N(S)2(-4)

Technical data

  • Type of control voltage
    AC

Other technical data

  • Type of switch drive
    Motor drive
  • Rated control supply voltage AC 60 Hz
    0 ... 0 V
  • Voltage type for actuating
    DC
  • Rated control supply voltage AC 50 Hz
    0 ... 0 V
  • Rated control supply voltage DC
    24 ... 30 V

Bulk packaging

A kind of package Skrzynia
Quantity 1 pcs.
Weight (kg) 1,330
Volume (m3) 0,002
Width (m) 0,105
Length (m) 0,150
Depth (m) 0,105
