Power circuit breaker BZM 50A (25kA) 109723
local index:
ALI345MOEL
Catalog No:
109723
EAN code:
4015081093090
Price:
247,53 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
BZM power circuit breaker with a rated current of 50A and a switching capacity of 25kA
Technical data
-
Rated current [A]50
-
Switching capacity [kA]25
Other technical data
-
Rated permanent current Iu50 A
-
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz25 kA
-
Adjustment range short-term delayed short-circuit release0 ... 0 A
-
Integrated earth fault protectionNo
-
Device constructionBuilt-in device fixed built-in technique
-
DIN rail (top hat rail) mounting optionalYes
-
Number of auxiliary contacts as normally open contact0
-
With switched-off indicatorNo
-
Number of poles3
-
Type of control elementRocker lever
-
Motor drive integratedNo
-
Degree of protection (IP)IP20
-
Rated voltage415 ... 415 V
-
Overload release current setting0 ... 0 A
-
Adjustment range undelayed short-circuit release480 ... 720 A
-
Type of electrical connection of main circuitScrew connection
-
Suitable for DIN rail (top hat rail) mountingNo
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as change-over contact0
-
Z wyzwalaczem podnapięciowymNo
-
Position of connection for main current circuitFront side
-
Complete device with protection unitYes
-
Motor drive optionalNo
Bulk packaging
| A kind of package | Skrzynia | Karton |
| Quantity | 1 pcs. | 12 pcs. |
| Weight (kg) | 0,852 | 10,309 |
| Volume (m3) | 0,001 | 0,016 |
| Width (m) | 0,080 | 0,180 |
| Length (m) | 0,133 | 0,385 |
| Depth (m) | 0,090 | 0,230 |
