Narrow profile interface relay: 1Z - one transistor output 2A PIR6WB-1PS-230VAC/DC-O 857532
local index:
APC031RELP
Catalog No:
857532
Price:
25,26 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print
Ask about the product
Product description
Narrow-profile interface relay: 1 NO - one transistor output 2 A. Width 6.2 mm. Spring clamps. Output (interchangeable - RSR30 relay, code "O"): transistor 1Z - terminals: (+)13 - (-)14; DC1 - 2 A / 24 V. Input - terminals: A1 - A2 - any polarity, supply voltage Un - 230 V AC/DC. Dimensions: 98.3 x 6.2 x 84.6mm. Mounting on a 35 mm rail. IP 20.
Technical data
-
Level of securityIP20
-
Width [mm]6.2
Other technical data
-
Type of electric connectionSpring clamp connection
-
Rated control supply voltage AC 60 Hz230 ... 230 V
-
Voltage type for actuatingAC/DC
-
Drive, switching attitudeMono stable
-
Type of switch contactSingle contact
-
Degree of protection (IP)IP20
-
Height98.3 mm
-
Rated control supply voltage AC 50 Hz230 ... 230 V
-
Rated control supply voltage DC230 ... 230 V
-
Drive, polarizationPolarity free
-
Number of contacts as change-over contact1
-
Complete with socketYes
-
Width6.2 mm
-
Depth84.6 mm
Manufacturer details
-
ManufacturerRELPOL S.A.
-
Address68-200 Żary 11 Listopada 37
-
Phone number
-
E-mail
-
Tax identification number9280007076
-
GLN5909000713000
