KNX RF QUICKLINK S.1/B.3/B.7 Button 4-way white matt 85648188

local index:
AIK074BERK
Catalog No:
85648188
EAN code:
4011334381648
Manufacturer: BERKER
Material: Thermoplastic
Surface: Matt
Family: KNX RF QUICKLINK
Price:
244,47 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

4-way button from the KNX RF quicklink series. Main design line: Berker S.1/B.3/B.7.

Features:

  • Additional ETS features: +6 scenes , 1 push-button control up/down, operating mode on/off, dimming value, light intensity indicator, push-button switch, status indicator, forced control
  • possibility of free configuration of functions of the area of upper/lower and left buttons/ on the right side: as a receiver to control the connected load or as a transmitter to remotely control e.g. blinds
  • possibility to configure the functions of the transmitter and/or receiver
  • reset function (to factory settings) ;
  • the ability to disable the memory of scenes
  • for plasterboard walls

Controls and indicators:

  • the ability to configure user interfaces for one- or two-level operation
  • with a configuration and function button

LED control:

  • with configuration and function LED
  • cap and mechanism compatibility LED indicator

Connection:

< ul>
  • integration with the KNX-TP system via the KNX radio network/surface-mounted TP gateway
  • Series characteristics:

    KNX quicklink to wireless alternative to the intelligent building technology system. An innovative wireless control system using radio communication in the KNX RF standard, without the need for complex cable routing. It has an extremely simple programming method.

    • installation in places where cable installation is not possible (e.g. glass walls),
    • the possibility of supplementing the traditional installation with additional functionality using a radio control system without high costs,
    • the ability to control electrical receivers using remote controls,
    • the ability to create light scenes and group and central control functions.

    Technical data

    • Material
      Thermoplastic
    • Family
      KNX RF QUICKLINK
    • Radio transmitter/receiver frequency [MHz]
      868.3
    • Number of radio channels
      4
    • Radio transmitter power [mA]
      <10
    • Relative humidity (no condensation) [%]
      0 - 65 (non-condensing)
    • Radio transmitter range (in open area) [m]
      100
    • Surface
      Matt
    • Operating temperature range [°C]
      from -5 to 45
    • Receiver category
      2
    • Number of quicklinks
      up to 20 transmitters/receivers
    • Radio protocol
      KNX
    • Range of the radio transmitter (in the building) [m]
      thirty
    • PKWIU
      26.51.20.0

    Other technical data

    • Bus system KNX
      No
    • Bus system radio frequent
      No
    • Bus system Powernet
      No
    • Radio frequent bidirectional
      Yes
    • Material quality
      Thermoplastic
    • Surface finishing
      Matt
    • RAL-number (similar)
      9010
    • Bus system KNX-RF (Radio Frequent)
      Yes
    • Bus system LON
      No
    • Other bus systems
      None
    • Material
      Plastic
    • Surface protection
      Untreated
    • Colour
      White
    • Transparent
      No

    Bulk packaging

    A kind of package Karton Pakiet Paleta
    Quantity 1 pcs. 1 pcs. 36 pcs. 1152 pcs.
    Weight (kg) 0,055 0,080 3,145 120,630
    Width (m) 0,056 0,084 0,300 0,800
    Length (m) 0,028 0,070 0,225 1,050
    Depth (m) 0,056 0,085 0,400 1,200
