KNX RF QUICKLINK S.1 Button 4-fold cream gloss 85648182

local index:
AIK071BERK
Catalog No:
85648182
EAN code:
4011334381624
Manufacturer: BERKER
Material: Thermoplastic
Surface: Gloss
Family: KNX RF QUICKLINK
Price:
244,95 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

4-way button from the KNX RF quicklink series. Main design line: Berker S.1. For product no.: 8512 11 00, 8512 12 00, 8512 22 00, 8542 11 00, 8542 12 00, 8542 21 00 8502 01 00, 8542 17 00

Features:

  • additional ETS functions: +6 scenes, 1 push-button control up/down, operating mode on/off, dimming value, illuminance indicator, push-button switch, status indicator, forced control
  • possibility to freely configure the function of the area of the upper/lower and left/right buttons: as a receiver to control the connected load or as a transmitter for remote control of e.g. blinds
  • possibility to configure the transmitter function and/or receiver
  • reset function (to factory settings) ;
  • possibility of blocking the memory of scenes
  • for plasterboard walls

Controls and indicators:

  • user interfaces can be configured for one- or two-level operation
  • with configuration and function button
  • LED control:

    • with configuration and function LED
    • cap and mechanism compatibility LED indicator
    • Connection:

      • integration with the KNX-TP system via the KNX radio network/TP surface-mounted gateway

      < strong>Series characteristics:

      KNX quicklink is a wireless alternative to the intelligent building technology system. An innovative wireless control system using radio communication in the KNX RF standard, without the need for complex cable routing. It has an extremely simple programming method.

      • installation in places where cable installation is not possible (e.g. glass walls),
      • the possibility of supplementing the traditional installation with additional functionality using a radio control system without high costs,
      • the ability to control electrical receivers using remote controls,
      • the ability to create light scenes and group and central control functions.

Technical data

  • Material
    Thermoplastic
  • Family
    KNX RF QUICKLINK
  • Radio transmitter/receiver frequency [MHz]
    868.3
  • Number of radio channels
    4
  • Radio transmitter power [mA]
    <10
  • Relative humidity (no condensation) [%]
    0 - 65 (non-condensing)
  • Radio transmitter range (in open area) [m]
    100
  • Surface
    Gloss
  • Operating temperature range [°C]
    from -5 to 45
  • Receiver category
    2
  • Number of quicklinks
    up to 20 transmitters/receivers
  • Radio protocol
    KNX
  • Range of the radio transmitter (in the building) [m]
    thirty
  • PKWIU
    26.51.20.0

Other technical data

  • Bus system KNX
    No
  • Bus system radio frequent
    No
  • Bus system Powernet
    No
  • Radio frequent bidirectional
    Yes
  • Material quality
    Thermoplastic
  • Surface finishing
    Glossy
  • RAL-number (similar)
    1013
  • Bus system KNX-RF (Radio Frequent)
    Yes
  • Bus system LON
    No
  • Other bus systems
    None
  • Material
    Plastic
  • Surface protection
    Untreated
  • Colour
    White
  • Transparent
    No

Bulk packaging

A kind of package Karton Pakiet Paleta
Quantity 1 pcs. 1 pcs. 36 pcs. 1152 pcs.
Weight (kg) 0,067 0,082 3,392 133,544
Width (m) 0,071 0,085 0,300 0,800
Length (m) 0,015 0,070 0,225 1,050
Depth (m) 0,071 0,085 0,400 1,200
