Circuit breaker, 4-pole, 630A, 50kA, installation and cable protection, fixed installation 110904

Name: Circuit breaker, 4-pole, 630A, 50kA, installation and cable protection, fixed installation
Brand: EATON
SKU: ALM113MOEL
Price: 13366.99 PLN
Availability: BackOrder

Místní index:

ALM113MOEL

Katalogové číslo.:

110904

EAN kód:

4015081104338

Circuit breaker, 4-pole, 630A, 50kA, installation and cable protection, fixed installation

Kliknutím na obrázek jej zvětšíte

Výrobce: EATON

Number of poles: 4

Installation: Constant

Rated current [A]: 630

Zobrazit celý popis

Cena:

13 366,99 zł

gross / kusů.

(včetně DPH 23%)

do 4 týdnů

Na zakázku

Množství kusů.

(vícenásobné:

)

Přidat do žádosti o cenovou nabídku

Přidat do schránky

Vytisknout

Dotaz na výrobek

Popis produktu Technické údaje Podrobnosti o výrobci Velkoobjemová balení Soubory ke stažení

Popis produktu

The circuit breakers of the NZM..-AE series are suitable for all applications and the IEC market with just four compact sizes. Assembly is always flexible with modular functional groups. With electronic release to protect installations and cables. Tips: The set value in the neutral conductor is synchronous to the set value of the outer conductor lr. RMS measurement and thermal memory

Technické údaje

Number of poles

4
Rated current [A]

630
Switching capacity [kA]

50

Installation

Constant
Series

Protection of installations and cables

Další technické údaje

Rated permanent current Iu

630 A
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz

50 kA
Adjustment range short-term delayed short-circuit release

0 ... 0 A
Integrated earth fault protection

Yes
Device construction

Built-in device fixed built-in technique
DIN rail (top hat rail) mounting optional

No
Number of auxiliary contacts as normally open contact

0
With switched-off indicator

No
Number of poles

4
Type of control element

Rocker lever
Motor drive integrated

No
Degree of protection (IP)

IP20

Rated voltage

690 ... 690 V
Overload release current setting

315 ... 630 A
Adjustment range undelayed short-circuit release

1260 ... 5040 A
Type of electrical connection of main circuit

Screw connection
Suitable for DIN rail (top hat rail) mounting

No
Number of auxiliary contacts as normally closed contact

0
Number of auxiliary contacts as change-over contact

0
With integrated under voltage release

No
Position of connection for main current circuit

Front side
Complete device with protection unit

Yes
Motor drive optional

Yes

Podrobnosti o výrobci

Výrobce

Eaton Electric Sp. z o.o.
Adresa

80-299 Gdańsk Galaktyczna 30 Polska
E-mail

wsparcietech@eaton.com

Velkoobjemová balení

Typ obalu	Skrzynia	Karton
Množství	1 kusů.	1 kusů.
Hmotnost (kg)	8,792	9,166
Objem (m3)	0,008	0,008
Šířka (m)	0,187	0,185
Délka (m)	0,168	0,166
Hloubka (m)	0,277	0,275
