BZM 80A (15kA) box power circuit breaker 109754

local index:
ALI360MOEL
Catalog No:
109754
EAN code:
4015081093403
Manufacturer: EATON
Rated current [A]: 80
Switching capacity [kA]: 15
Price:
205,74 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 4 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

BZM power circuit breaker with rated current 80A and switching capacity 15kA, box

Technical data

  • Rated current [A]
    80
  • PKWIU
    27.12.24.0
  • Switching capacity [kA]
    15

Other technical data

  • Rated permanent current Iu
    80 A
  • Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
    15 kA
  • Adjustment range short-term delayed short-circuit release
    0 ... 0 A
  • Integrated earth fault protection
    No
  • Device construction
    Built-in device fixed built-in technique
  • DIN rail (top hat rail) mounting optional
    Yes
  • Number of auxiliary contacts as normally open contact
    0
  • With switched-off indicator
    No
  • Number of poles
    3
  • Type of control element
    Rocker lever
  • Motor drive integrated
    No
  • Degree of protection (IP)
    IP20
  • Rated voltage
    415 ... 415 V
  • Overload release current setting
    0 ... 0 A
  • Adjustment range undelayed short-circuit release
    800 ... 1200 A
  • Type of electrical connection of main circuit
    Frame clamp
  • Suitable for DIN rail (top hat rail) mounting
    No
  • Number of auxiliary contacts as normally closed contact
    0
  • Number of auxiliary contacts as change-over contact
    0
  • Z wyzwalaczem podnapięciowym
    No
  • Position of connection for main current circuit
    Front side
  • Complete device with protection unit
    Yes
  • Motor drive optional
    No

Bulk packaging

A kind of package Skrzynia Karton
Quantity 1 pcs. 12 pcs.
Weight (kg) 0,852 10,309
Volume (m3) 0,001 0,016
Width (m) 0,080 0,180
Length (m) 0,133 0,385
Depth (m) 0,090 0,230
