3-pole circuit breaker, 90A, NZMN2-ME90 265778

local index:
ALP210MOEL
Catalog No:
265778
EAN code:
4015082657789
Manufacturer: EATON
Number of poles: 3
Rated current [A]: 90
Overload release [A]: 45-90
Price:
860,35 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 2 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

3-pole power switch 90A

Technical data

  • Number of poles
    3
  • Overload release [A]
    45-90
  • Switching capacity [kA]
    50
  • Rated current [A]
    90
  • Short-circuit release [A]
    2014-02-14 00:00:00

Other technical data

  • Overload release current setting
    45 ... 90 A
  • With thermal overload protection
    Yes
  • Switch off technique
    Electronic
  • Rated permanent current Iu
    90 A
  • Rated operation power at AC-3, 400 V
    45 kW
  • Type of control element
    Rocker lever
  • With integrated auxiliary switch
    No
  • Number of poles
    3
  • Degree of protection (IP)
    IP20
  • Width
    105 mm
  • Adjustment range undelayed short-circuit release
    90 ... 1260 A
  • Phase failure sensitive
    Yes
  • Rated operating voltage
    690 ... 690 V
  • Rated operation power at AC-3, 230 V
    22 kW
  • Type of electrical connection of main circuit
    Screw connection
  • Device construction
    Built-in device fixed built-in technique
  • With integrated under voltage release
    No
  • Rated short-circuit breaking capacity lcu at 400 V, AC
    35 kA
  • Height
    184 mm
  • Depth
    149 mm

Bulk packaging

A kind of package Skrzynia
Quantity 1 pcs.
Weight (kg) 2,546
Volume (m3) 0,003
Width (m) 0,105
Length (m) 0,149
Depth (m) 0,184
