V-TEC VM L32 LGR Metric Cable Gland Long 2022951
local index:
RRR175OBOB
Catalog number:
2022951
EAN code:
4012195004240
Manufacturer:
OBO BETTERMANN
Price:
12,51 zł
gross / pcs.
(including VAT 23%)
On request
Quantity pcs.
(multiplicity:
20
)
Add to inquiry
Add to clipboard
Print
Ask about the product
Technical data
Other technical data
-
Thread typeMetric
-
Pitch thread1.5 mm
-
Wrench width36 mm
-
Suitable for cable diameter15 ... 21 mm
-
Material qualityPolyamide (PA)
-
Glass-fibre reinforcedNo
-
Shock resistantNo
-
RAL-number7035
-
With locknutNo
-
Multi seal areaNo
-
With strain reliefYes
-
Type of sealingSealing ring
-
Operating temperature-20 ... 65 °C
-
For Ex-zone gasNone
-
Nominal thread size metric/PG32
-
Thread length15 mm
-
Hexagon angular dimension41 mm
-
MaterialPlastic
-
Halogen freeYes
-
Degree of protection (IP)IP68
-
ColourGrey
-
Bend radius protection/trumpet flareNo
-
ModelStraight
-
Flat cable couplingNo
-
Rodzaj odciążki zgodnie z normą EN 62444Typ A
-
Separable screw glandNo
-
Explosion-tested versionNo
-
For Ex-Zone dustNone
Manufacturer details
-
ManufacturerOBO Bettermann Holding GmbH & Co. KG
-
Address58710 Menden Hüingser Ring 52 Niemcy
-
E-mail
Bulk packaging
| A kind of package | Skrzynia | Karton | Paleta |
| Quantity | 20 pcs. | 240 pcs. | 4320 pcs. |
| Weight (kg) | 0,500 | 6,508 | 139,644 |
| Volume (m3) | 0,002 | 0,038 | 0,912 |
| Width (m) | 0,123 | 0,388 | 0,800 |
| Length (m) | 0,218 | 0,395 | 1,200 |
| Depth (m) | 0,087 | 0,249 | 0,950 |
