UNIVERS N Busbar block 4P Cu 25x4mm 4x250A 300x250mm UE21D2
local index:
RRR1R7HAGE
Catalog No:
UE21D2
EAN code:
3250616150560
Price:
448,31 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to inquiry
Add to clipboard
Print
Ask about the product
Product description
Sub-assembly/Block with a full cover, with busbars, from the univers N series, i.e. the switchgear enclosure system.
Technical data
-
Depth [mm]110
-
Number of poles4P
-
Fixingrail system
-
FamilyUNIVERS N
-
Height [mm]300
-
The distance between the rails40mm
-
Busbar height [mm]4
-
ColorWhite
-
MaterialPlastic
-
Rated current [A]250
-
Width [mm]250
-
Number of sections1
-
Busbar width [mm]25
-
PKWIU27.12.40.0
Other technical data
-
Height300 mm
-
Depth110 mm
-
Busbar distance40 mm
-
Busbar thickness25 mm
-
Width250 mm
-
Number of poles4
-
Busbar height4 mm
-
Max. rated current250 A
Manufacturer details
-
ManufacturerHager Electro GmbH & Co KG
-
AddressDE 66440 Blieskastel Zum Gunterstal Niemcy
-
E-mail
Bulk packaging
| A kind of package | Karton | Paleta | Karton | Paleta |
| Quantity | 1 pcs. | 96 pcs. | 1 pcs. | 96 pcs. |
| Weight (kg) | 2,550 | 245,370 | 2,550 | 245,370 |
| Width (m) | 0,260 | 0,800 | 0,260 | 0,800 |
| Length (m) | 0,110 | 1,070 | 0,110 | 1,070 |
| Depth (m) | 0,300 | 1,240 | 0,300 | 1,240 |
