UNIVERS IP65 polyester enclosure 550x1100mm FL34S

Name: UNIVERS IP65 polyester enclosure 550x1100mm
Brand: HAGER
SKU: RIH156HAGE
Price: 3997.11 PLN
Availability: BackOrder

Índice local:

RIH156HAGE

Número de catálogo:

FL34S

Código EAN:

3250616000315

UNIVERS IP65 polyester enclosure 550x1100mm

Haga clic en la foto para ampliar

Fabricante: HAGER

Depth [mm]: 300

Thickness [mm]: 2

Number of doors: 1

Ver descripción completa

Precio:

3 997,11 zł

gross / uds.

(IVA incluido 23%)

hasta 10 semanas

Por encargo

Cantidad uds.

(múltiple:

)

Añadir a solicitud de presupuesto

Añadir al portapapeles

Imprimir

Pregunta por el producto

Descripción del producto Datos técnicos Detalles del fabricante Empaquetado a granel Archivos para descargar

Descripción del producto

Housing made of polyester conditionally resistant to UV, from the univers series.

Series characteristics:

Cabinet systems are functional, not only as distribution switchgears (main power supply), but also as meter cabinets - they always form one, compact whole, while guaranteeing maximum safety.

Datos técnicos

Depth [mm]

300
Number of doors

1
Protection class

II
Housing material

Glass fiber reinforced polyester
Family

UNIVERS
Width [mm]

1100
Number of sections

4
Lock type

8mm 3-point pin
PKWIU

27.12.40.0

Thickness [mm]

2
Number of locks

1
Material

Polyester
Installation

Surface-mounted
Level of security

IP65
Height [mm]

550
Number of rows for cameras

3
Exact material

Glass fiber reinforced polyester

Otros datos técnicos

Mounting method

Surface mounted
Cover model

Closed
Transparent cover/door

No
Nominal current (In)

630 A
Width

1100 mm
Built-in depth

300 mm
Material plate thickness cabinet

2 mm
Colour

Grey
Number of modules

144
Width in number of modular spacings

48
Extension possible

No
Housing material

Plastic
With mounting plate

No
Suitable for lightning protection

Yes
Protection class

II
Circuit integrity

None

Type of covering

Cover
Type of door

Single
With lock

Yes
Height

550 mm
Depth

300 mm
Inner depth

150 mm
Material plate thickness door/cover

2 mm
RAL-number

7035
Number of rows

3
Number of openings for flange plates

0
Number of conduit inlets

0
Surface protection

Untreated
Suitable for outdoor use

Yes
Degree of protection (IP)

IP65
Impact strength

IK10
Cover with overpressure release

No
