UNIVERS IP41 upper enclosure closing cover with 2 holes for 1350x400 field FZ885WF

local index:
RRR3P0HAGE
Catalog No:
FZ885WF
EAN code:
7611919290760
Manufacturer: HAGER
Depth [mm]: 400
Thickness [mm]: 1
Material: Galvanized steel sheet
Price:
146,55 €
gross / pcs.
(including VAT 23%)
Delivery in 3h
up to 10 weeks (business days)
Pickup in 1h
Quantity pcs.
(multiplicity:
1
)
Add to clipboard
Print

Product description

Closing cover for floor-standing housing, top, with 2 holes per bay, univers N HC series.

Series characteristics:

Cabinet systems are characterized by the functionality of installation, not only as distribution switchgears (main power supply), but also as meter cabinets - they always form one, compact whole, while guaranteeing maximum safety.

Technical data

  • Depth [mm]
    400
  • Material
    Galvanized steel sheet
  • Family
    UNIVERS
  • Width [mm]
    1350
  • Surface finish
    Galvanized
  • PKWIU
    27.12.40.0
  • Thickness [mm]
    1
  • Fixing
    screwed
  • Level of security
    IP41
  • Height [mm]
    1.5
  • Number of cable entries
    10

Other technical data

  • Suitable for roof planking
    Yes
  • Width
    1350 mm
  • Depth
    373 mm
  • Suitable for enclosure building depth
    400 mm
  • Colour
    Other
  • Suitable for outdoor set-up
    No
  • Suitable for bottom planking
    No
  • Height
    1.25 mm
  • Suitable for enclosure building width
    1350 mm
  • Material
    Steel
  • With de-aeration
    No
  • With cable entry
    Yes

Bulk packaging

A kind of package Karton Paleta
Quantity 1 pcs. 1 pcs. 10 pcs.
Weight (kg) 3,100 3,200 57,000
Width (m) 1,350 0,370 1,170
Length (m) 0,015 0,005 1,050
Depth (m) 0,373 1,350 1,700
