UNIbox Uni-1 enclosure 43.1

Indice locale:
RIH036ELOP
Numero di catalogo:
43.1
Codice EAN:
5905548285719
Depth [mm]: 166
Level of security: IP65
Width [mm]: 300
Prezzo:
48,13 €
gross / pezzi
(inclusa IVA 23%)
Consegna in 3 ore
Accessibile 34 pezzi
Raccolta in 1h
Quantità pezzi
(multiplo:
1
)
Aggiungi alla richiesta di preventivo
Aggiungi agli appunti
Stampa

Descrizione del prodotto


Uni-box enclosures are constructions constituting a safe and aesthetic product for mounting low voltage units, "S" type fuse units, single and three-phase meters, control devices such as ;also other electric devices.

Enclosures are made of gray PC (polycarbonate) plastic, equipped with a gasket for high tightness parameters, perforated mounting plate, gray or transparent door on hinges closed with one or two hinges ch locks with a key . Versatility of use and precisely made elements in the end result in a solidly made and aesthetically-looking housing.

Dati tecnici

  • Depth [mm]
    166
  • Width [mm]
    300
  • PKWIU
    27.12.31.0
  • Level of security
    IP65
  • Height [mm]
    400

Altri dati tecnici

  • Width
    300 mm
  • Depth
    160 mm
  • Material quality
    ABS
  • Colour
    Grey
  • With mounting plate
    Yes
  • Suitable for wall built-in
    No
  • Number of doors
    1
  • With ventilation door
    No
  • Number of locks
    2
  • Pitched roof
    No
  • Impact strength
    IK07
  • Degree of protection (NEMA)
    5
  • Height
    400 mm
  • Material
    Plastic
  • Surface finishing
    Untreated
  • RAL-number
    7035
  • Mounting plate depth-adjustable
    No
  • Pole fastening
    No
  • With glazed door
    No
  • With rear door
    No
  • Suitable for metrical mounting
    No
  • EMC-version
    Yes
  • Degree of protection (IP)
    IP65

Dettagli del produttore

  • Produttore
    Z.P.H. ELEKTRO-PLAST Sp. z o.o.
  • Indirizzo
    62-860 Opatówek Rogatka 14 Polska

Imballaggio sfuso

Una specie di pacchetto Sztuka
Quantità 1 pezzi
Peso (kg) 0,382
Larghezza (m) 0,182
Lunghezza (m) 0,325
Profondità (m) 0,410
